20T Rail Transfer car movement on longitudinal rail and crossing rails
20T Rail Transfer car movement on longitudinal rail and crossing rails
Specifications
Brand Name :
Topleader
Model Number :
KPD-5T
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1 set
Price :
$11000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
600 sets/year
Delivery Time :
40 days after your prepayment
Packaging Details :
The whole cart will be packed by the tarp, the parts will be packed by polywood case.
Product name :
20T Transfer car movement on longitudinal rail and crossing rails
Power supply :
Low voltage 36v
Material :
Q235 Steel
Load capacity :
1-300T
Running speed :
20m/min
Application :
inplant, production line
Warranty :
1 year
Color :
customized
OEM :
Accepted
Description

20T Rail Transfer car movement on longitudinal rail and crossing rails

working principle :
20T Rail Transfer car powered by the 36V single-phase (three phase) low voltage rail, which through sliding wire to complete. Ground step-down transformer control cabinet will be single phase (three phase) AC 380V step-down to single-phase (3Phase) 36V, sent to the flat car by the rail sliding wire, and then step-up (three phase) single-phase AC 380V by step-up transformers on the car, provide electricity for the single-phase capacitor motors which used in the car.
20T Rail Transfer car movement on longitudinal rail and crossing rails
Functions & Advantages Of motorized platform trolley on railways
  • 20t rail transfer cart solve two carts problem on different direction rails and save room.
  • 20t rail transfer cart is powered by low voltage electricity from the railway;
  • It has lifting function for switch the rails.
  • It make the rail transfer cart most optimized assembly
Technical Parameters of rail transfer cart
Model KPDZ-20T
Rated Load(t) 5
Table size(mm) 5000*2500*650
Wheel Base(mm) 3800
Rail Gauge(mm) 1435
Wheel Diameter(mm) Ф350
Wheel Quantity(Pcs) 4
Ground Clearance(mm) 50
Running Speed(m/min) 0-20
Motor Power(Kw) 1.5
Transformer Power(KVA) 5
Transformer Quantity(Set) 1
Running Distance(m) 60
Max Wheel Load(KN) 100
Reference Weight(t) 2.2
Recommended Rail Model P24

Application of rail transfer cart

rail transfer cart is applied in mold plant, foundry plant for injection, plastic mold handling. We can design the size and lifting demand as per client using demand.

20T Rail Transfer car movement on longitudinal rail and crossing rails

Product Name

rail transfer cart
Material
Cast steel, Q235B
Table size
5000*2500*600mm( other dimensioncan be customized)
Color
customized
Certificate
CE, SGS, ISO9001, SAS0
Advantages
Safety, flexibility, stable start
High using frequency
No restriction of the running time
Simple operation and High efficiency
Application
mold plant, foundry plant
Producing line of motorized platform trolley on railways
20T Rail Transfer car movement on longitudinal rail and crossing rails
Details of motorized platform trolley on railways
20T Rail Transfer car movement on longitudinal rail and crossing rails
Packing & Delivery of motorized platform trolley on railways

Packing Details : The whole painting line use transfer cart carriage is packed by the tarp, the parts will be packed by polywood case
Delivery Details : 3-30 days after order of Solid bicycle tire tubes

20T Rail Transfer car movement on longitudinal rail and crossing rails
Customers
20T Rail Transfer car movement on longitudinal rail and crossing rails
20T Rail Transfer car movement on longitudinal rail and crossing rails
