Industrial Pallet Transfer Carts 30ton Battery Power Transfer Vehicle With Lifting Function
Industrial Pallet Transfer Carts 30ton Battery Power Transfer Vehicle With Lifting Function
Industrial Pallet Transfer Carts 30ton Battery Power Transfer Vehicle With Lifting Function
Industrial Pallet Transfer Carts 30ton Battery Power Transfer Vehicle With Lifting Function
Industrial Pallet Transfer Carts 30ton Battery Power Transfer Vehicle With Lifting Function
Industrial Pallet Transfer Carts 30ton Battery Power Transfer Vehicle With Lifting Function
Industrial Pallet Transfer Carts 30ton Battery Power Transfer Vehicle With Lifting Function
Industrial Pallet Transfer Carts 30ton Battery Power Transfer Vehicle With Lifting Function
Specifications
Brand Name :
Topleader
Model Number :
BWP
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1 set
Price :
$5000-$15000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
600 sets/year
Delivery Time :
50 days after receive your prepayment
Packaging Details :
The whole Battery Power Transfer Vehicle will be packed by the tarp, the parts will be packed by polywood case.
Product name :
Industrial Pallet Transfer Carts 30ton Battery Power Transfer Vehicle With Lifting Function
Power supply :
battery power
Material :
Q235 Steel plate and PU wheel
Load capacity :
1-100T
Running speed :
0-20m/min
Application :
shop to shop, interbay, inplant
Warranty :
12 month
Color :
customized
Battery type :
Lithium battery
Description

Industrial Pallet Transfer Carts 30ton Battery Power Transfer Vehicle With Lifting Function


Working Principle of battery power transfer vehicle


Industrial Pallet Transfer Carts 30ton Battery Power Transfer Vehicle With Lifting Function is powered by lithium battery. The battery is installed in the steerable trolley and we also equip intelligent charger for it. The 30t battery power transfer vehicle is controlled to go forward, backward, turn left, turn right, adjust speed through PLC and speed controller.

Industrial Pallet Transfer Carts 30ton Battery Power Transfer Vehicle With Lifting Function


Description of battery power transfer vehicle


The 30ton battery power transfer vehicle is composed of motor, reducer, electric appliance and wheels. Due to more parts, compared with other carts, it has large size. But it travels flexibly.
The driving wheel and load wheel of industrial pallet transfer cart is high strength PU wheel. It is wear-resistance, and has low maintain cost.
The functions of the 30ton battery power transfer vehicle including 360 degree turning, go forward and backward, turn left and right, up and down adjust speed button, indicator light, electric indicator light and other control buttons. It has operating platform and can make the operator stand on the carriage to operate.

Industrial Pallet Transfer Carts 30ton Battery Power Transfer Vehicle With Lifting Function

Main Parts Photo of battery power transfer vehicle


Industrial Pallet Transfer Carts 30ton Battery Power Transfer Vehicle With Lifting Function


Application of battery power transfer vehicle


This kind of 30ton battery power transfer vehicle is commonly applied in factory workshop or warehouse to transfer materials, such as injection mold, steel coil, machine parts, aluminium coil, etc.


Industrial Pallet Transfer Carts 30ton Battery Power Transfer Vehicle With Lifting Function


Technical Parameters of battery power transfer vehicle

Model

BWP-30T

Rated Load(t)

30 t

Impacted rated load(t)

45

structure of frame

steel plates welded beam structure

Thickness of the steel plate

14

Cart weight(t)

8.8

Wheel load(t)

7.7

Ground requirement

cement ground

Table size(mm)

5000x2200

Height of the whole cart(mm)

650

Space from the ground(mm)

50

Wheels distance

1700

Axles distance

4300

Turning radius(mm)

4300

Turning type

turning while driving without stop

Control method for turning

control button

Turning structure

mechanical

Wheel diameter

Ф400/4

Wheel quality

polyurethane wheels

Running speed(m/min)

0-12

Brake principle

electric magnetic force

Operation method

with wire or no wire

Charger motor's installation

installed on cart

Function of charger motor

automatic charging

Warning equipment

sound and light lamp

Manufacturing of battery power transfer vehicle


Industrial Pallet Transfer Carts 30ton Battery Power Transfer Vehicle With Lifting Function


Delivery of battery power transfer vehicle


Industrial Pallet Transfer Carts 30ton Battery Power Transfer Vehicle With Lifting Function
