Best Price 45t Steel Bar Rail Transfer Battery Operated Handling Cart
Best Price 45t Steel Bar Rail Transfer Battery Operated Handling Cart
Best Price 45t Steel Bar Rail Transfer Battery Operated Handling Cart
Best Price 45t Steel Bar Rail Transfer Battery Operated Handling Cart
Best Price 45t Steel Bar Rail Transfer Battery Operated Handling Cart
Best Price 45t Steel Bar Rail Transfer Battery Operated Handling Cart
Best Price 45t Steel Bar Rail Transfer Battery Operated Handling Cart
Best Price 45t Steel Bar Rail Transfer Battery Operated Handling Cart
Best Price 45t Steel Bar Rail Transfer Battery Operated Handling Cart
Best Price 45t Steel Bar Rail Transfer Battery Operated Handling Cart
Specifications
Brand Name :
Topleader
Model Number :
KPD
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1 set
Price :
$4000-$10000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
600 sets/year
Delivery Time :
30-40 days after receive your prepayment
Packaging Details :
The whole transfer cart will be packed by the tarp, the parts will be packed by polywood case.
Product name :
Best price 45t steel bar rail transfer battery operated handling cart
Power supply :
battery power
Size :
Customized
Load capacity :
1-500T
Running speed :
30m/min(adjust)
Application :
Factory,warehouse and working line
Warranty :
1 year
Color :
Customized
OEM :
Accepted
Description

Best price 45t steel bar rail transfer battery operated handling cart

Brief Introduction

The best price 45t steel bar rail transfer battery operated handling cart is flat construction and has a load capacity of 30 tons. The surface size of the cart is customized according to customer needs. Lithium batteries provide power, and flat cart forward, backward, turn. We will be equipped with a remote control, which can be more convenient to manipulate the flat cart transportation of various equipment. Cast steel wheels do not deform easily. If you are interested in this product, please contact us.

Best Price 45t Steel Bar Rail Transfer Battery Operated Handling Cart

Features and Advantages

1. It has high a nti-explosion and a nti-high temperature performance.

2. Electric transfer cart has no strict requirement for the construction of the railway .

3. It has safe and flexible movement, which is also convenient to use.

4. The transfer cart can be applied in many occasions, such as easy explosion, high temperature, ferry.

5. The transfer cart can run on the Vertical rails, ”L”rails, “S”rails, arc-shaped rails.

Best Price 45t Steel Bar Rail Transfer Battery Operated Handling Cart

Parameter List --- Low Voltage Railway Power Electric Transfer Cart

Model
 KPD-2T KPD-5T KPD-10T KPD-20T KPD-30T KPD-40T KPD-50T KPD-63T
Rated load (T) 2 5 10 20 30 40 50 63
Table size length(L) 2000 3500 3600 4000 4500 5000 5500 5600
Width(W) 1500 2000 2000 2200 2200 2500 2500 2500
Height(H) 450 450 500 550 600 650 650 750
Wheel Base (mm) 1200 2500 2600 2800 3200 3800 4200 4300
Rail Inner Gauge (mm) 1200 1435 1435 1435 1435 1435 1435 1435
Wheel Diameter(mm) Φ270 Φ300 Φ300 Φ350 Φ400 Φ500 Φ500 Φ600
Wheel Quantity(Nos) 4 4 4 4 4 4 4 4
Ground Clearance (mm) 50 50 50 50 50 50 50 75
Running speed (m/min) 0-25 0-25 0-25 0-20 0-20 0-20 0-20 0-20
Motor Power (Kw) 1 1.2 1.6 2.2 3.5 4 5 6.3
Transformer Power (KVA) 3 5 5 6.8 10 10 10 20
Transformer Quantity (Pcs) 1 1 1 1 1 1 1 1
Running Distance (m) 80 80 80 80 80 60 50 50
Max Wheel Load (KN) 14.4 25.8 42.6 77.7 110.4 142.8 174 221.4
Reference Weight (T) 2.8 3.6 4.2 5.9 6.8 7.6 8 10.8
Recommended Rail Model P15 P18 P18 P24 P38 P43 P43 P50

Application

It has a wide range of applications such as material handling in factories or warehouses, transporting goods between different workstations at airports or ports as well as loading/unloading materials from trucks or ships. With its heavy duty construction and robust design the series steel plate rail cart ensures dependable performance even under harsh weather conditions making it perfect for any industrial environment where reliability is essential. Additionally its low maintenance requirements make it ideal for cost-effective operations over time.

Best Price 45t Steel Bar Rail Transfer Battery Operated Handling Cart

Shipping --- Low Voltage Railway Power Electric Transfer Cart

Best Price 45t Steel Bar Rail Transfer Battery Operated Handling Cart

About Us--- Low Voltage Railway Power Electric Transfer Cart

Best Price 45t Steel Bar Rail Transfer Battery Operated Handling Cart

Best Price 45t Steel Bar Rail Transfer Battery Operated Handling CartBest Price 45t Steel Bar Rail Transfer Battery Operated Handling CartBest Price 45t Steel Bar Rail Transfer Battery Operated Handling Cart
