200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart
200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart
200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart
200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart
200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart
200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart
200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart
200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart
200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart
200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart
Specifications
Brand Name :
Topleader
Model Number :
BWP
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1 set
Price :
$7000-$12000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
600 sets/year
Delivery Time :
50 days after your prepayment
Packaging Details :
The whole transfer cart will be packed by the tarp, the parts will be packed by polywood case.
Product name :
200T laser detect sensor battery power steerable heavy duty cart
Power supply :
Storage battery
Material :
steel
Load capacity :
1-100T
Running speed :
0-20m/min
Application :
Factory ,warehouse and working line
Warranty :
1 year
Color :
customized
OEM :
Accepted
Description

200T laser detect sensor battery power steerable heavy duty cart

Product Introduction

200T laser detect sensor battery power steerable heavy duty cart running distance is not limited, the use of battery power. The service life of the battery is related to the frequency of use of the battery. The wheel material of the transfer cart is polyurethane coated with rubber wheels, so it will not cause damage to the ground when running, and it can also run on hard ground or slightly uneven ground. The flat cart is equipped with alarm lights to remind the staff to pay attention to safety. The flat car is also equipped withlaser detect sensor that can detect obstacles around it during operation.


200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart

Parts Details

200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart

200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart


Safe Operation

1. The staff must wear all labor protection and protective equipment before entering the workshop, otherwise they are not allowed to enter the production workshop.

2. Before using the electric flat car, it is necessary to check whether the exterior of the vehicle is in good condition, whether the transmission mechanism and its lubrication condition are normal, remove the production waste or large obstacles stacked on both sides of the track and in the middle, and items that may affect the normal use of the electric flat car, start The use signal should be issued before work.

3. During the operation of the electric flat car, avoid sudden start and sudden stop, to prevent the danger of slipping of the inertial load and the occurrence of safety accidents.

200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart


Technical Parameters

Model BWP-3T
Rated Load(t) 3t
Impacted rated load(t) 3.2
structure of frame steel plates welded beam structure
Thickness of the steel plate 12
Cart weight(t) 1
Wheel load(t) 7.7
Ground requirement cement ground
Table size(mm) 3000x1200
Height of the whole cart(mm) 650
Space from the ground(mm) 50
Wheels distance 1700
Axles distance 4300
Turning radius(mm) 4300
Turning type turning while driving without stop
Control method for turning control button
Turning structure mechanical
Wheel diameter Ф400/4
Wheel quality polyurethane wheels
Running speed(m/min) 0-12
Brake principle electric magnetic force
Operation method with wire or no wire
Charger motor's installation installed on cart
Function of charger motor automatic charging
Warning equipment sound and light lamp

Advantages

1.Our cart can be customized.According to specific demands, we will design auxiliary devices and basic drawings for users free of charge, and provide technical services and drawing materials.；

2.Provide users with free technical consultation, technical training, and answer product-related questions；

3.During the warranty period, when the product is damaged or does not work properly due to quality problems, the user will be repaired or replaced with accessories free of charge.

200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart


Production Process


200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart

Packing&Shipping


200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart

Our Company

200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart
200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart

200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart


After-sale Service

  • Our commitment: The load bearing safety factor of the trolley is no less than 120%.

  • Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material.

  • 16 hours engineering service and 24 hours internet service for our customers.

  • During the warranty period, if our products can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours.

  • Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.

  • 200T Laser Detect Sensor Battery Power Steerable Heavy Duty Cart
