Electrical Battery Power 25ton Rail Cart Transfer
Electrical Battery Power 25ton Rail Cart Transfer
Electrical Battery Power 25ton Rail Cart Transfer
Electrical Battery Power 25ton Rail Cart Transfer
Electrical Battery Power 25ton Rail Cart Transfer
Electrical Battery Power 25ton Rail Cart Transfer
Electrical Battery Power 25ton Rail Cart Transfer
Electrical Battery Power 25ton Rail Cart Transfer
Electrical Battery Power 25ton Rail Cart Transfer
Electrical Battery Power 25ton Rail Cart Transfer
Specifications
Brand Name :
Topleader
Model Number :
KPD
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1 set
Price :
$4000-$10000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
600 sets/year
Delivery Time :
30-40 days after receive your prepayment
Packaging Details :
The whole transfer cart will be packed by the tarp, the parts will be packed by polywood case.
Product name :
Electrical Battery Power 25ton Rail Cart Transfer
Power supply :
battery power
Size :
Customized
Load capacity :
1-1500T
Running speed :
30m/min(adjust)
Application :
Factory,warehouse and working line
Warranty :
1 year
Color :
Customized
Materials :
Steel
Description

Electrical Battery Power 25ton Rail Cart Transfer

Brief Introduction

The body surface of the electrical battery power 25ton rail cart transfer is equipped with a thickened steel plate, which can reduce the damage of heavy objects to the body. The battery is installed inside the transfer cart and provides power to the electric trolley by controlling the motor, so that the transfer cart runs. The battery has a good battery life, usually eight hours of use. We provide our customers with portable charging units, which have a small footprint and are easy to place.


Battery track flat cart run on tracks, so tracks need to be installed at the workplace. Transfer cart on the track can drive straight, forward, backward, turn and so on. A handle placement box is installed on the side of the flat car, which can store the handle controller and remote control.
Our company has more than 20 years of customization experience, we will provide you with the most suitable solution according to the customer's working conditions.

Electrical Battery Power 25ton Rail Cart Transfer

Electrical Battery Power 25ton Rail Cart Transfer

Features and Advantages

1. It has high a nti-explosion and a nti-high temperature performance.

2. Electric transfer cart has no strict requirement for the construction of the railway .

3. It has safe and flexible movement, which is also convenient to use.

4. The transfer cart can be applied in many occasions, such as easy explosion, high temperature, ferry.

5. The transfer cart can run on the Vertical rails, ”L”rails, “S”rails, arc-shaped rails.

Electrical Battery Power 25ton Rail Cart Transfer

Parameter List --- Low Voltage Railway Power Electric Transfer Cart

Model
 KPD-2T KPD-5T KPD-10T KPD-20T KPD-30T KPD-40T KPD-50T KPD-63T
Rated load (T) 2 5 10 20 30 40 50 63
Table size length(L) 2000 3500 3600 4000 4500 5000 5500 5600
Width(W) 1500 2000 2000 2200 2200 2500 2500 2500
Height(H) 450 450 500 550 600 650 650 750
Wheel Base (mm) 1200 2500 2600 2800 3200 3800 4200 4300
Rail Inner Gauge (mm) 1200 1435 1435 1435 1435 1435 1435 1435
Wheel Diameter(mm) Φ270 Φ300 Φ300 Φ350 Φ400 Φ500 Φ500 Φ600
Wheel Quantity(Nos) 4 4 4 4 4 4 4 4
Ground Clearance (mm) 50 50 50 50 50 50 50 75
Running speed (m/min) 0-25 0-25 0-25 0-20 0-20 0-20 0-20 0-20
Motor Power (Kw) 1 1.2 1.6 2.2 3.5 4 5 6.3
Transformer Power (KVA) 3 5 5 6.8 10 10 10 20
Transformer Quantity (Pcs) 1 1 1 1 1 1 1 1
Running Distance (m) 80 80 80 80 80 60 50 50
Max Wheel Load (KN) 14.4 25.8 42.6 77.7 110.4 142.8 174 221.4
Reference Weight (T) 2.8 3.6 4.2 5.9 6.8 7.6 8 10.8
Recommended Rail Model P15 P18 P18 P24 P38 P43 P43 P50

Application

It has a wide range of applications such as material handling in factories or warehouses, transporting goods between different workstations at airports or ports as well as loading/unloading materials from trucks or ships. With its heavy duty construction and robust design the series steel plate rail cart ensures dependable performance even under harsh weather conditions making it perfect for any industrial environment where reliability is essential. Additionally its low maintenance requirements make it ideal for cost-effective operations over time.

Electrical Battery Power 25ton Rail Cart Transfer

Shipping --- Low Voltage Railway Power Electric Transfer Cart

Electrical Battery Power 25ton Rail Cart Transfer

About Us--- Low Voltage Railway Power Electric Transfer Cart

Electrical Battery Power 25ton Rail Cart Transfer

Electrical Battery Power 25ton Rail Cart TransferElectrical Battery Power 25ton Rail Cart TransferElectrical Battery Power 25ton Rail Cart Transfer
