Towed Cable Electric Motorized Cart Moving On Rails
Towed Cable Electric Motorized Cart Moving On Rails
Towed Cable Electric Motorized Cart Moving On Rails
Towed Cable Electric Motorized Cart Moving On Rails
Towed Cable Electric Motorized Cart Moving On Rails
Towed Cable Electric Motorized Cart Moving On Rails
Towed Cable Electric Motorized Cart Moving On Rails
Towed Cable Electric Motorized Cart Moving On Rails
Specifications
Brand Name :
Topleader
Model Number :
Rail Transfer Cart
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1 set
Price :
$3000-$12000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
600 sets/year
Delivery Time :
30-40 days after receive your prepayment
Packaging Details :
The whole Material Handling Transfer Cart will be packed by the tarp, the parts will be packed by polywood case.
Product name :
Towed Cable Electric Motorized Cart Moving On Rails
Power supply :
Electric Power or Custom
Key Words :
motorized cart moving on rails
Load capacity :
1-300T
Running speed :
0-20m/min
Application :
Factory ,warehouse and working line
Warranty :
1 year
Color :
customized
OEM :
Accepted
Description

Towed Cable Electric Motorized Cart Moving On Rails

Introduction

Electric flat cart is a good helper for heavy material handling. The motorized cart is powered by a cable, and the length of the cable depends on how far the flat car needs to run. In order to avoid the danger caused by the irregular placement of cables during the running of the handling trolley, we will install the wiring device and conductor post for the flat cart. This electric transfer car runs on rails, and its wheels are made of cast steel. The electric flat car powered by cable has the advantages of simple structure, low cost and unrestricted use frequency.

The workers need to lay the track in advance according to the designated route of transportation, and the flat car runs on the track to the working point. The rail cars can also turn depending on customer requirements.

The parts and materials used in our electric flat cars are of good quality. If you need a transportation plan, please contact us.

Towed Cable Electric Motorized Cart Moving On RailsTowed Cable Electric Motorized Cart Moving On Rails

Product Advantages

Towed Cable Electric Motorized Cart Moving On Rails

Detail

Towed Cable Electric Motorized Cart Moving On Rails

Parameter List

Rated load (T)

2

10

20

30

50

63

150

Table size

length(L)

2000

3600

4000

4500

5500

5600

10000

Width(W)

1500

2000

2200

2200

2500

2500

3000

Height(H)

450

500

550

600

650

700

1200

Wheel Base (mm)

1200

2600

2800

3200

4200

4300

7000

Rail Inner Gauge (mm)

1200

1435

1435

1435

1435

1435

2000

Wheel Diameter(mm)

Φ270

Φ300

Φ350

Φ400

Φ500

Φ600

Φ600

Wheel Quantity

4

4

4

4

4

4

8

Ground Clearance (mm)

50

50

50

50

50

75

75

Running speed (min)

0-25

0-25

0-20

0-20

0-20

0-20

0-18

Max Wheel Load (KN)

14.4

42.6

77.7

110.4

174

221.4

265.2

Reference Weight (t)

2.8

4.2

5.9

6.8

8

10.8

26.8

Recommended Rail Model

P15

P18

P24

P38

P43

P50

QU100

Application

Towed Cable Electric Motorized Cart Moving On Rails

About Us

Towed Cable Electric Motorized Cart Moving On Rails

Towed Cable Electric Motorized Cart Moving On RailsTowed Cable Electric Motorized Cart Moving On Rails

Towed Cable Electric Motorized Cart Moving On Rails
