Battery Powered Motorized 15 Ton Crane Transfer Cart Applied In Working Site
Battery Powered Motorized 15 Ton Crane Transfer Cart Applied In Working Site
Battery Powered Motorized 15 Ton Crane Transfer Cart Applied In Working Site
Battery Powered Motorized 15 Ton Crane Transfer Cart Applied In Working Site
Battery Powered Motorized 15 Ton Crane Transfer Cart Applied In Working Site
Battery Powered Motorized 15 Ton Crane Transfer Cart Applied In Working Site
Battery Powered Motorized 15 Ton Crane Transfer Cart Applied In Working Site
Battery Powered Motorized 15 Ton Crane Transfer Cart Applied In Working Site
Specifications
Brand Name :
Topleader
Model Number :
BWP
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1 set
Price :
$8000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
600 sets/year
Delivery Time :
30-40 days after receive your prepayment
Packaging Details :
The whole crane transfer cart will be packed by the tarp, the parts will be packed by polywood case.
Product name :
Battery Powered Motorized 15 Ton Crane Transfer Cart Applied In Working Site
Power supply :
Battery powered
Material :
steel
Load capacity :
1-300T
Running speed :
0-20m/min
Application :
Factory,warehouse and working line
Warranty :
1 year
Color :
customized
OEM :
Accepted
Description

Battery powered motorized 15 ton crane transfer cart applied in working site

Brief Introduction - 15 Ton Crane Transfer Cart

KPX series 15 ton crane transfer carts are battery powered. The transfer cart can be used both on the “S” and arc-shaped railways. This series transfer carts are more safe and flexible and running distance is not limited. It has no strict requirement for the construction of the railway. The crane transfer cart is suitable to be used in the long distance transportation, and it is a great solution of industry heavy materials handling.

Battery Powered Motorized 15 Ton Crane Transfer Cart Applied In Working Site

Advantages - 15 Ton Crane Transfer Cart

No need install rail, no any damage to the floor

It can realized double way moving and 360 degree turning

DC drive and heavy loading capacity

small turning radius, flexible operation

Braking distance is short, and have alarming system

Battery Powered Motorized 15 Ton Crane Transfer Cart Applied In Working Site

Working principle - 15 Ton Crane Transfer Cart

The battery are installed in the carts. The battery supplies electricity to the DC motor through the electrical control system. We use this principle to make the cart start, stop, move forward, move backward, adjust the speed etc.

Battery Powered Motorized 15 Ton Crane Transfer Cart Applied In Working Site

Application - 15 Ton Crane Transfer Cart

The battery operated transfer cart is applied to transfer steel ladles or steel scrap ladle in steel factory and meturallgy plant. Generally the load capacity is large, can reach to 150 tons. It is commonly applied in steel plant, mechallurgy industry, aluminum factory, plastic pipes factory, etc. to transfer rounded material, from producing line to store.

Battery Powered Motorized 15 Ton Crane Transfer Cart Applied In Working Site

Parameters - 15 Ton Crane Transfer Cart

Model
 BWP-2T BWP-10T BWP-20T BWP-30T BWP-50T BWP-80T BWP-100T
Rated load (T) 2 10 20 30 50 80 100
Table size length(L) 2000 2300 2400 3500 5500 6500 6600
Width(W) 1500 2000 2200 2200 2600 2800 3000
Height(H) 450 500 600 700 800 950 1200
Wheel Base (mm) 1080 1650 2800 1650 2000 1950 2000
Axle Base (mm) 1380 1850 1435 2700 2850 3500 4000
Wheel Diameter(mm) Φ250 Φ400 Φ350 Φ450 Φ600 Φ600 Φ600
Wheel Quantity(Nos) 4 4 4 4 4 4 8
Ground Clearance (mm) 50 50 50 50 50 75 75
Running speed (m/min) 0-25 0-25 0-20 0-20 0-20 0-20 0-18
Motor Power (Kw) 2*1.2 2*2.2 2*4.5 2*5.5 2*7.5 30 40
Battery Capacity(Ah) 250 250 400 450 500 800 1000
Battery Voltage(V) 24 48 48 48 72 72 72
Running Time When Full Load 2.5 2.8 2.2 2 2.5 2 1.9
Running Distance for one Charge(Km) 3 3.4 2.7 2.4 3 32.4 2.3
Max Wheel Load (KN) 14.4 42.6 77.7 110.4 174 185 190
Reference Weight (t) 2.3 4.2 5.9 6.8 8 14.6 26.8
Battery Powered Motorized 15 Ton Crane Transfer Cart Applied In Working Site

Packing & Delivery - 15 Ton Crane Transfer Cart

The crane transfer cart will be packed by the tarp, the parts will be packed by polywood case.

Battery Powered Motorized 15 Ton Crane Transfer Cart Applied In Working Site
