Industrial Motorized Material Handling Battery Driven Transfer Cart Transport Carriage With Battery Drive
Industrial Motorized Material Handling Battery Driven Transfer Cart Transport Carriage With Battery Drive
Industrial Motorized Material Handling Battery Driven Transfer Cart Transport Carriage With Battery Drive
Industrial Motorized Material Handling Battery Driven Transfer Cart Transport Carriage With Battery Drive
Industrial Motorized Material Handling Battery Driven Transfer Cart Transport Carriage With Battery Drive
Industrial Motorized Material Handling Battery Driven Transfer Cart Transport Carriage With Battery Drive
Industrial Motorized Material Handling Battery Driven Transfer Cart Transport Carriage With Battery Drive
Industrial Motorized Material Handling Battery Driven Transfer Cart Transport Carriage With Battery Drive
Specifications
Brand Name :
Topleader
Model Number :
KPX-Transfer Cart
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1 set
Price :
$3000-$12000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
600 sets/year
Delivery Time :
30-40 days after receive your prepayment
Packaging Details :
The whole Battery Driven Transfer Cart will be packed by the tarp, the parts will be packed by polywood case.
Product name :
Industrial Motorized Material Handling Battery Driven Transfer Cart Transport Carriage With Battery Drive
Power supply :
Battery Powered
Key Words :
Battery Driven Transfer Cart
Load capacity :
1-300T
Running speed :
0-30m/min(adjust)
Application :
Factory ,warehouse and working line
Warranty :
1 year
Color :
Customized
OEM :
Accepted
Description

Industrial Motorized Material Handling Battery Driven Transfer Cart Transport Carriage With Battery Drive

Product Introduction --- Battery Driven Transfer Cart

About the Industrial Motorized Material Handling Battery Driven Transfer Cart Transport Carriage With Battery Drive, the battery installed in the transfer cart, and the battery driven the motor to make the transfer cart working.

Compare wtih KPJ, KPD series, it is of the greater flexibility in security and mobility.The running distance is not limited and without demand of rail isolation, so the construction is convenient and the cost is low.

This type of battery driven transfer cart can provide the following optional parts for the customer to further improve the efficiency of (1) maintenance-free battery (2) import Promise speed control, dual speed control (3) the import of industrial wireless remote control.

Industrial Motorized Material Handling Battery Driven Transfer Cart Transport Carriage With Battery Drive

Product Details --- Battery Driven Transfer Cart

Industrial Motorized Material Handling Battery Driven Transfer Cart Transport Carriage With Battery Drive

Parameter --- Battery Driven Transfer Cart

Model

KPX-2T

KPX-10T

KPX-20T

KPX-30T

KPX-50T

KPX-63T

KPX-150T

Rated load (T)

2

10

20

30

50

63

150

Table size

length(L)

2000

3600

4000

4500

5500

5600

10000

Width(W)

1500

2000

2200

2200

2500

2500

3000

Height(H)

450

500

550

600

650

700

1200

Wheel Base (mm)

1200

2600

2800

3200

4200

4300

7000

Rail Inner Gauge (mm)

1200

1435

1435

1435

1435

1435

2000

Wheel Diameter(mm)

Φ270

Φ300

Φ350

Φ400

Φ500

Φ600

Φ600

Wheel Quantity

4

4

4

4

4

4

8

Ground Clearance (mm)

50

50

50

50

50

75

75

Running speed (m/min)

0-25

0-25

0-20

0-20

0-20

0-20

0-18

Motor Power (Kw)

1

1.6

2.2

3.5

5

6.3

15

Battery Capacity(Ah)

180

160

180

250

330

400

600

Battery Voltage(V)

24

48

48

48

48

48

72

Running Time When Full Load

4.32

4.8

4

3.5

3.3

3

2.9

Running Distance for one Charge(Km)

6.5

7.2

4.8

4.2

4

3.6

3.2

Max Wheel Load (KN)

14.4

42.6

77.7

110.4

174

221.4

265.2

Reference Weight (t)

2.8

4.2

5.9

6.8

8

10.8

26.8

Recommended Rail Model

P15

P18

P24

P38

P43

P50

QU100

Industrial Motorized Material Handling Battery Driven Transfer Cart Transport Carriage With Battery Drive

Applications --- Battery Driven Transfer Cart

The battery driven transfer cart can be widely used in assembly line (ring production line, loop production line), metallurgy industry (steel ladle), warehouse transport, ship industry (maintenance, assemble, container transport), workpiece transport in workshop, lathe transport, steel factory (steel billet, steel plate, steel coil, steel pipe, section steel, steel structure), construction(bridge, simple building, concrete, concrete column), petroleum industry (oil pump, sucker rod and parts), energy (polycrystalline silicon, generator, windmill), chemical industry (electrolytic cell, retort etc), railway (rail maintenance, rail welding, train tractor).

Industrial Motorized Material Handling Battery Driven Transfer Cart Transport Carriage With Battery Drive

Customer Visit

Industrial Motorized Material Handling Battery Driven Transfer Cart Transport Carriage With Battery Drive

Processing Flow

Industrial Motorized Material Handling Battery Driven Transfer Cart Transport Carriage With Battery Drive

Our After-Sale Service

  • Our commitment: The load bearing safety factor of the trolley is no less than 120%.

  • Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material.

  • 16 hours engineering service and 24 hours internet service for our customers.

  • During the warranty period, if our products can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours.

  • Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.
