Specifications
Brand Name :
Topleader
Model Number :
BWP
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1 set
Price :
$5000-$15000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
600 sets/year
Delivery Time :
50 days after receive your prepayment
Packaging Details :
The whole mould trackless handling truck will be packed by the tarp, the parts will be packed by polywood case.
Product name :
Can Turn Electric Operated Transport Handling Mould Trackless Handling Truck
Power supply :
battery
Material :
Q235 Steel plate and PU wheel
Load capacity :
75t
Running speed :
0-20m/min
Application :
Factory ,warehouse and working line
Warranty :
12 month
Color :
yellow
Battery type :
Lead acid battery
Description

Can Turn Electric Operated Transport Handling Mould Trackless Handling Truck

Working principle of mould trackless handling truck


Can Turn Electric Operated Transport Handling Mould Trackless Handling Truck is powered by lead acid battery. The battery is installed in the mould trackless handling truck and we also equip intelligent charger for it. The 75t battery powered wheel mould trackless handling truck is controlled to go forward, backward, turn left, turn right, adjust speed through PLC and speed controller.

Trackless mould trackless handling truck has different movement track, so the price do.The small table size trackless mould trackless handling truck generally use the lithium battery and cos will be higer than ordinary battery.

The battery operated mould trackless handling truck can increase night light, collision strip for safety operation.

Can Turn Electric Operated Transport Handling Mould Trackless Handling Truck

Description of mould trackless handling truck
The mould trackless handling truck on cement floor get power from storage battery of 24v, 36v, 48v and 72v. Then the DC motor drives the trackless cart to start, stop, go forward and backward and adjust its speed. Trackless coil cart with a “v” support is specialized to transfer heavy cargoes of all kind of cargoes. The wheels is specially designed to avoid destruction to the ground.The functions of the mould trackless handling truck including 360 degree turning, go forward and backward,turn left and right, adjust speed button, indicator light, electric indicator light and other control buttons. It has operating platform and can make the operator stand on the carriage to operate.

Can Turn Electric Operated Transport Handling Mould Trackless Handling Truck


Main parts photo of mould trackless handling truck


Can Turn Electric Operated Transport Handling Mould Trackless Handling Truck Can Turn Electric Operated Transport Handling Mould Trackless Handling Truck Can Turn Electric Operated Transport Handling Mould Trackless Handling Truck
Can Turn Electric Operated Transport Handling Mould Trackless Handling Truck Can Turn Electric Operated Transport Handling Mould Trackless Handling Truck Can Turn Electric Operated Transport Handling Mould Trackless Handling Truck

Application of mould trackless handling truck

workshop, automotive mold, material transfer, aerospace equipment workshop, air conditioning workshop, casting mold factory Large mold, aluminum coil, steel coil, steel, steel ingot, boiler, casting module
Materials: large molds, aluminum coils, steel coils, steel, steel ingots, boilers, casting modules.


Can Turn Electric Operated Transport Handling Mould Trackless Handling Truck

Technical parameter of mould trackless handling truck

Model BWP-75T
Rated Load(t) 75t
Impacted rated load(t) 65
structure of frame steel plates welded beam structure
Thickness of the steel plate 14
Cart weight(t) 15
Wheel load(t) 55
Ground requirement cement ground
Table size(mm) 5000x2200
Height of the whole cart(mm) 1000
Space from the ground(mm) 50
Wheels distance 1700
Axles distance 4300
Turning radius(mm) 4300
Turning type turning while driving without stop
Control method for turning control button
Turning structure mechanical
Wheel diameter Ф600/4
Wheel quality polyurethane wheels
Running speed(m/min) 0-12
Brake principle electric magnetic force
Operation method with wire or no wire
Charger motor's installation installed on cart
Function of charger motor automatic charging
Warning equipment sound and light lamp


Manufacturing of mould trackless handling truck


Can Turn Electric Operated Transport Handling Mould Trackless Handling Truck

Delivery of mould trackless handling truck
Can Turn Electric Operated Transport Handling Mould Trackless Handling Truck
Our sale performance

No. Exported countries Product name Product model Quantity Unit
1 Thailand Rail transfer cart KPDZ-16T 2 sets
2 Germany Battery power transfer car KPX-10T 2 sets
3 Syria Battery power transfer car KPX-120T 1 set
4 Syria Battery power transfer car KPX-30T 1 set
5 Turkey Battery power transfer car KPX-40T 3 sets
6 South Africa Battery power transfer car KPX-6T 2 sets
7 Nepal Battery power transfer car KPX-6T 2 sets
8 Singapore Cable power transfer car KPJ-15T 1 set
9 Singapore Cable power transfer car KPJ-10T 1 set
10 Singapore Towed transfer car KP-15T 1 set

11

 Mongolia Cable power transfer car KPJ-30T 2 sets
12 Saudia Arabia Cable power transfer car KPX-60T 2 sets
13 Austrilia Battery power transfer car KPX-60T 1 set
14 Singapore Hoist trolley HB-4T 1 set
15 Singapore Hoist trolley HB-15T 2 sets
16 India Battery power transfer car KPX-20T 1 set
17 Singapore Electric turntable 2 sets
18 Mexico cable power transfer car KPJ-60T 1 set
19 Turkey cable power transfer car KPJ-10T 1 set
20 Saudia Arabia Busbar powered transfer car KPC-10T 1 set
In order to protect clients' information, client's company names keep secret

Our company

Can Turn Electric Operated Transport Handling Mould Trackless Handling TruckCan Turn Electric Operated Transport Handling Mould Trackless Handling Truck

Customer visit in our factory from wordwide


Can Turn Electric Operated Transport Handling Mould Trackless Handling Truck

Our client feedback

Can Turn Electric Operated Transport Handling Mould Trackless Handling Truck

RFQ for mould trackless handling truck

1.table size, payload?

2.turning radius you allowed?

3.Indoor or outdoor?

4.Min height for the operation platform
