300 Ton Machinery Industry Steel Plate Plant Motorized Load Transport Wagon
300 Ton Machinery Industry Steel Plate Plant Motorized Load Transport Wagon
300 Ton Machinery Industry Steel Plate Plant Motorized Load Transport Wagon
300 Ton Machinery Industry Steel Plate Plant Motorized Load Transport Wagon
300 Ton Machinery Industry Steel Plate Plant Motorized Load Transport Wagon
300 Ton Machinery Industry Steel Plate Plant Motorized Load Transport Wagon
300 Ton Machinery Industry Steel Plate Plant Motorized Load Transport Wagon
300 Ton Machinery Industry Steel Plate Plant Motorized Load Transport Wagon
Specifications
Brand Name :
topleader
Model Number :
BWP
Certification :
CE,ISO,SASO
Place of Origin :
China
MOQ :
1 set
Price :
US$15000-20000/set
Supply Ability :
300 SET/MONTH
Delivery Time :
30 DAYS
Packaging Details :
The whole load transport wagon is packed by tarp, the parts are packed by the wooden case.
Item :
300 Ton Machinery Industry Steel Plate Plant Motorized Load Transport Wagon
Material :
Q235B steel
Load capacity :
1-300 Ton
Table size :
Customized
Speed :
0-20m/min
Color :
Customized
Application :
industry
Delivery time :
45 days
Cargo transported :
heavy cargoes
Key Words :
load transport wagon
Description

300 Ton Machinery Industry Steel Plate Plant Motorized Load Transport Wagon

Brief Introduction of Load Transport Wagon

Load transport wagon system is a kind of handling system in mold factory. It is powered by battery and can turn with 360 degree; The speed is 0-15m/min, start steadily and gradually accelerate to ensure the cargo transportation safety. It runs on plane floor in the bay of factory. Easy to operate and be convenient to use. No running distance limitation and don't need rails.

300 Ton Machinery Industry Steel Plate Plant Motorized Load Transport Wagon

Custom Options of Load Transport Wagon

Flat decks or fixtures customized for specific loads.

Custom deck configurations including built-in scales and lift/tilt/rotate capabilities.

Track or trackless, non-guided steering. Alternative drive and steering systems including gear reducer axle drives and individually-controlled drive wheels.

Fixed or variable speeds with forward/reverse function.

Drives with acceleration/deceleration capabilities.

Variety of operator control systems including fixed user interface, pendant control on coil cord, and radio-controlled remote operation.

Safety features including horns, flashing lights, e-stops, bumpers and collision avoidance systems.

300 Ton Machinery Industry Steel Plate Plant Motorized Load Transport Wagon

Application of Load Transport Wagon

The electric flat transfer vehicle is mainly applied in assembly line, metallurgy industry, warehouse transport, ship industry, work piece transport in workshop, lathe transport, steel factory, construction, petroleum industry, energy, chemical industry, railway, etc.

300 Ton Machinery Industry Steel Plate Plant Motorized Load Transport Wagon

Parameter of Load Transport Wagon

Model
 BWP-2T BWP-10T BWP-20T BWP-30T BWP-50T BWP-80T BWP-100T
Rated load (T) 2 10 20 30 50 80 100
Table size length(L) 2000 2300 2400 3500 5500 6500 6600
Width(W) 1500 2000 2200 2200 2600 2800 3000
Height(H) 450 500 600 700 800 950 1200
Wheel Base (mm) 1080 1650 2800 1650 2000 1950 2000
Axle Base (mm) 1380 1850 1435 2700 2850 3500 4000
Wheel Diameter(mm) Φ250 Φ400 Φ350 Φ450 Φ600 Φ600 Φ600
Wheel Quantity(Nos) 4 4 4 4 4 4 8
Ground Clearance (mm) 50 50 50 50 50 75 75
Running speed (m/min) 0-25 0-25 0-20 0-20 0-20 0-20 0-18
Motor Power (Kw) 2*1.2 2*2.2 2*4.5 2*5.5 2*7.5 30 40
Battery Capacity(Ah) 250 250 400 450 500 800 1000
Battery Voltage(V) 24 48 48 48 72 72 72
Running Time When Full Load 2.5 2.8 2.2 2 2.5 2 1.9
Running Distance for one Charge(Km) 3 3.4 2.7 2.4 3 32.4 2.3
Max Wheel Load (KN) 14.4 42.6 77.7 110.4 174 185 190
Reference Weight (t) 2.3 4.2 5.9 6.8 8 14.6 26.8

300 Ton Machinery Industry Steel Plate Plant Motorized Load Transport Wagon

About Us

Xinxiang New Leader Machinery Manufacturing Co., Ltd is devoted to manufacture and sell lifting and handling equipment. We can produce 1-500 ton range of various tonnage of KPD rail low voltage series, KPJ cable reel series, KPC safety sliding line series, KPX battery powered series, BWP rubber wheel transfer cart series, KPT towed cable series, KP non-power type seven series which including turning electric flat car, trackless electric flat car, ladle car, ferry electric flat car, hydraulic lifting electric transfer car, electric winch, rail wheel and so on more than 90 products.
