Specifications
Brand Name :
Topleader
Model Number :
KPT
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1 set
Price :
$5000-$12000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
600 sets/year
Delivery Time :
30-40 days after receive your prepayment
Packaging Details :
The whole cart will be packed by the tarp, the parts will be packed by polywood case.
Product name :
Plant Material Interbay Slab Deck Transfer Track Mounted Ttoneable Die Truck
Power supply :
Cable chain
Material :
steel
Load capacity :
1-300T
Running speed :
20m/min
Application :
Factory ,shop,warehouse
Warranty :
1 year
Color :
customized
OEM :
Accepted
Description

Plant Material Interbay Slab Deck Transfer Track Mounted Ttoneable Die Truck

toneable die truck introduction

Plant Material Interbay Slab Deck Transfer Track Mounted Ttoneable Die Truck

toneable die truck are powered by the mobile cable. It conducts AC 380V directly into the electrical control system of the toneable die truck to let it start, stop, go forward and backward and so on. The cart is powered by dragging cable which is laid on the ground. The cable line is placed between the two rails. The operation system is low voltage 36V power.. With its simple structure and low price, KPT mobile cable cart is more often used to transfer materials for a short distance from one workshop to another.

.

Advantage of toneable die truck

Contiunous work

Have a 150mm lifting height

Can move on level line and vertical movement

Similar to the forklift, but longer working time than it.

Plant Material Interbay Slab Deck Transfer Track Mounted Ttoneable Die Truck

toneable die truck details:

Plant Material Interbay Slab Deck Transfer Track Mounted Ttoneable Die Truck

Parameter of toneable die truck

Model KPT-15T
Rated Load(t) 15
Table size(mm) 2000*1500*450
Wheel Base(mm) 1200
Rail Gauge(mm) 1200
Wheel Diameter(mm) Ф300
Wheel Quantity(Pcs) 4
Ground Clearance(mm) 50
Running Speed(m/min) 25
Motor Power(Kw) 2
Max Wheel Load(KN) 14.4
Reference Weight(t) 3
Recommended Rail Model P24


toneable die truck application

This toneable die truck is suitable for occasions with a running distance of less than 20m, a high frequency of use and a low vehicle height. Due to the simple mechanism and low cost, it is a common toneable die truck with a cross-span of the workshop. Tows can be used to reduce cable wear in slower speeds. The running distance of this series of toneable die truck should not be too long, generally less than 20m. Due to the simple mechanism and low cost, it is a common toneable die truck in the workshop. It can be used in the occasion of short running distance and slow running speed. To reduce cable wear, it is suitable for occasions with high frequency of use and low vehicle height. The running distance of this series of toneable die truck is generally less than 20m. In the case of slow running speed and short running distance, the drag chain can be used to reduce the wear of the cable. The mechanism is simple and the cost is low. It is a common cross-track flat in the workshop. The car is suitable for occasions with high frequency of use and low vehicle height.

Plant Material Interbay Slab Deck Transfer Track Mounted Ttoneable Die Truck

CUSTOM VISIT

Plant Material Interbay Slab Deck Transfer Track Mounted Ttoneable Die Truck

Our customer feedback

Plant Material Interbay Slab Deck Transfer Track Mounted Ttoneable Die Truck

Processing flow

Plant Material Interbay Slab Deck Transfer Track Mounted Ttoneable Die Truck

Our after-sale service

  • Our commitment: The load bearing safety factor of the trolley is no less than 120%.

  • Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material.

  • 16 hours engineering service and 24 hours internet service for our customers.

  • During the warranty period, if our products can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours.

  • Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.
