Manufacturer direct supply stamping 90 degree metal joint pipe fittings pipe joint system bracket

Product introduction

The 30 degree fixed metal joint only need one pair of M6 * 25 bolts to complete the installation process. And its surface has equipotential lines, the thickness of 30 degree fixed metal joint is 2.5mm, which can ensure that it has a strong bearing capacity. After the joint is grinded, the burr on the joint surface can be greatly reduced or even completely cleared, effectively reducing the risk of injury to workers in the workplace. The joint has nickel plating, zinc plating, chromium plating and black surface treatment. And the surface treatment of the joint adopts electroplating, which can effectively prevent its rusting and prolong the service life of the joint.

Features

1. Two equipotential lines on both sides of the product, so the installation position of the tube can be known when using. Auxiliary user installation.

2.The thickness of the product is up to 2.5, 25% thicker than most products, with stronger performance and higher bearing capacity.

3. Holes are reserved on the surface of the product, and self-tapping screws can be inserted later to better fix the pipe.

4. Products can be customized with logos and marked with models according to different needs of customers.

Application

LiefTech 30 degree fixed metal joint is used for the movement and fixation of the circuit board peripheral car frame. A pair of M6 * 25 bolts is required to fix and connect the two lean pipes at 30 degrees. Moreover, the connection between the connector and the lean pipe conforms to human mechanics. 30 degree fixed metal joint is often used in various material racks and turnover vehicles. It is the most commonly used joint in the lean pipe system.
