Specifications
Brand Name :
HANJING
Model Number :
P5mm outdoor digital signage LED Display
Certification :
CE/ROHS/FCC/ETL/TUV
Place of Origin :
ShenZhen,China
MOQ :
1pc/1sqm
Price :
Negotiation
Payment Terms :
35% T/T as prepayment,65% T/T as balance at factory, Western Union, MoneyGram
Supply Ability :
>600sqm/month
Delivery Time :
8-25 working days after received your payment
Packaging Details :
Plywood cartons or flight case packaging
Model :
P5mm outdoor LED Display
Cabinet Size(WXH) :
640mm ×640mm
Cabinet Resolution :
128 dots × 128 dots
Brightness :
5500nits
Color Processing depth :
16 bit
IP rating :
IP65
Cabinet Material :
Aluminum
Operating environment :
outdoor:-30℃-60℃;humidity:10%-90%RH
Description

P5mm-SMD-640mx640m-IP65

P5mm Electronic Outdoor Advertising Led Display Screen For Large Companies / Small Institutions
P5mm outdoor digital signage LED Display/outdoor led screen/outdoor led signs​

For Outdoor fixed installation application;
SMD LED Display;
Weatherproof to IP65/65 standards;
High resolution images and long lifetime;
Easily configured for various size and aspect ratios;
Wide viewing angle;
Brightness from 5500 nits onwards.

UV against;
High brightness;
Waterproof and dust proof;
Excellent flatness;
High refresh rate allows for good performance of live program;
Wide viewing angle: 140 degree both horizontal and vertical;
Easily configured for various sizes and aspect ratios.

P5mm outdoor led screen SMD Outdoor LED displays use excellent SMD for outdoor application. The SMD LED is capsulated with good uniformity and heat dissipation. They have wider viewing angle, up to 140 both horizontal and vertical. They also adopt anti-UV design to protect the display body.

Outdoor Advertising LED Display Other Corresponding product specifications :
P3mm outdoor Advertising led screen

P3.91mm outdoor Advertising led screen

P4.81mm outdoor Advertising led screen
P4mm outdoor Advertising led screen
P5mm outdoor Advertising led screen
P6mm outdoor Advertising led screen
P8mm outdoor Advertising led screen
P10mm outdoor Advertising led screen
P16mm outdoor Advertising led screen
P25mm outdoor Advertising led screen
P31.25mm outdoor Advertising led screen


P5mm outdoor digital signage LED Display Specifications:

Item Technical Parameters
Screen model HJ-P5mm
Led encapsulation SMD3528
Led configuration 1R1G1B
Pixel pitch(mm/inch) 64*32mm
Red chip Wavelength range: 619-628nm, 5nm;
Brightness range:700-1000mcd
Green chip Wavelength range: 461-470nm, 4nm;
Brightness range: 1400-1700mcd
Blue chip Wavelength range: 522-531nm, 4nm;
Brightness range: 350-500mcd
Resolution 40000dots/㎡
Maintenance Front-maintained
Brightness: CD/sq.ft (CD/㎡) >511CD/sq.ft (5500 CD/㎡)
Refreshing frequency: Hz >960 Hz
Grey scale 16bit
Module pixel W 32 × H 32 dots
Module size W 192 × H 192 mm
Viewing angle Horizontal: 120°, Vertical: 120°
Cabinet material Aluminum/steel
Lightness uniformity Pixel & module>90%
Cabinet color Customized
Driving method 1/8 scan constant current
Driving IC MBI5041/MBI5024/JXI5020
Cabinet size Cabinet size could be adjustable by demands
Power supply 85-264VAC, typical value: 110VAC/220VAC
Max consumption Max.≤89.12W/sq.ft (960W/㎡)
Average consumption Ave.: 29.73-44.59w/sq.ft(Ave.:320-480w/㎡)
Led life time ≥100000hours
Mean time to failure ≥5000hours
Module plainness ≤1mm
Pixel out of control less than 1/ 10⁻⁴, dispersion state
Working temperature -30ºC to +60ºC
Working humidity 20% to 90%
Waterproof IP lamp & top:IP65, other part:IP54
Protection function dampproof/dust-free/anti high temp/anti-thunder/ anti electromagnetic interference, etc
Certificate CCC /CE/UL/Rohs/Tuv
Hardware interface Standard PC network interface technology/U disc/3G
Display mode 24 bit true color
Colors 281 trillion colors
Colour processing ability ≥16bit
Color temperature 3000K ≤ TC ≤9000K, adjustable
Brightness regulating degrees continuously adjustable step by step through the software
Anty-Y correction curve Anti-γ correction system: 2.2-2.8 adjustable
Image adjust White balance/contrasting / hue control/ Single point brightness adjustment
Image processing mage noise reduction/ image enhancement/ image motion compensation/ Image color coordinate transformation processing/ Image passivation treatment
Correction technology Yes
Video mode AVI, WMV, MPG, MOV, DAT, VOB, MP4, FLV
Controlling platform Windows
