High Brightness P4mm Outdoor Advertising LED Display SMD2121 Panel Long Life Span
High Brightness P4mm Outdoor Advertising LED Display SMD2121 Panel Long Life Span
High Brightness P4mm Outdoor Advertising LED Display SMD2121 Panel Long Life Span
High Brightness P4mm Outdoor Advertising LED Display SMD2121 Panel Long Life Span
Specifications
Brand Name :
HANJING
Model Number :
P4mm
Certification :
CE/ROHS/FCC
Place of Origin :
ShenZhen，China
MOQ :
1pc/1sqm
Price :
Negotiation
Payment Terms :
35% T/T as prepayment,65% T/T as balance at factory,USD
Supply Ability :
600 sets per month
Delivery Time :
25-30 working days after received your payment
Packaging Details :
Wooden package or flight package
Color :
Full color RGB
Material :
Die-casting aluminium/iron
Pixels :
4mm outdoor led display
Screen :
Customized
Brightness :
6000 cd/sqm
Warranty :
2 Years
Life span :
100000hours
Led type :
SMD2121
Description

Specifications:

Module Technical Parameters
Pixel Pitch 4mm
LED Type SMD2121
Module Size (mm) 320mm*160mm
Module Resolution 80dots*40dots
Module weight 0.23kg
Brightness ≤800 nit
Refresh Rate ≥1920 Hz
Driving Method 1/20scan
Grey level 16bits
Color Display 281 trillion
IP Grade IP31
Power consumption (Max/Average) 600/200 W/sq.m
LifeSpan 100000 hour
Cabinet
Cabinet Size(WXH) 640mm*640mm
Cabinet resolution 128*128 Pixeles
Cabinet Material Die-cast Aluminum
Cabinet weight(kg) 8kg
Pixel density 25000 Pixeles /m²
Installation Flat Installation And Arc Installation
Control system Full color asynchronous /synchronous
Data interconnection Wifi / USB / HDMI
Software PC software or Android App or IOS App
Application environment
Input AC power voltage 110V-240V
Working temperature indoor:-20℃~50℃
Working humidity humidity:10%-90%RH
Signal type(with video processor) AV, S-Video, VGA, DVI, HDMI, SDI, DP
Control distance HSYV: <100m; SMF: <10km

Full Color Outdoor P4 LED Screen for advertising with high brightness, good uniformity, good stability and good waterproof

Product Features:

1. SMD led encapsulation technology confirm the wide view angle up to 140 degree for horizontal and vertical, and good uniformity,less than 0.1mm difference

2. High quality leds with black body with high contrast,high brightness up to 6500nits

3. Good Waterproof IP65, can be used under heavy rain weather and humid area

4. Stability Iron cabinets for fixed installation, with fast lock and aviation plugs, conveninet to install and dismantle

5. High quality, meet the request of international standard of CE, FCC,RoHs

6. Long life span >100000hours, and 3 year warranty

7, Vivid and exact picture, minimum noise, advanced test equipment, support any PC operation system and play a variety of information likevideo, word, flash, music, clock, graph etc.
8, High brightness and support brightness automatically adjustment.
9, Long lifespan, can reach more than 100, 000 hours, while the power consumption is lower than one tenth of lamp or neon;
10, Easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display system;
11, Rich outdoor full color LED display screen engineering experience both in domestic and international market.

High Brightness P4mm Outdoor Advertising LED Display SMD2121 Panel Long Life Span
High Brightness P4mm Outdoor Advertising LED Display SMD2121 Panel Long Life Span

High Brightness P4mm Outdoor Advertising LED Display SMD2121 Panel Long Life Span
