Professional Film Lighting HMI Par Light M40 6000K with Universal Ballast
Professional Film Lighting HMI Par Light M40 6000K with Universal Ballast
Professional Film Lighting HMI Par Light M40 6000K with Universal Ballast
Professional Film Lighting HMI Par Light M40 6000K with Universal Ballast
Specifications
Brand Name :
GENERALINK
Model Number :
GL-PAR M40
Certification :
CE, ROHS
Place of Origin :
CHINA
Delivery Time :
3-8 working days
Item Type :
Film Lighting
Lamp Power :
2500W/4000W 230V
Light Head type :
Open Face with Reflector
Beam Angle :
20-60 °
Dimming :
50-100%
Bulb socket / lamp base: :
G38
Color Temeperature :
6000K
Lamp Body Material :
Aluminium Alloy
Weight :
19 KG
Measurement :
670 * 402 * 511mm
Warranty :
1 year
Description

Professional Film Lighting HMI Par Light M40 with Univeral Ballast

1. OVERVIEW:
Together with our flicker-free Electronic Ballasts, our HMI Fresnel Lights and HMI Par Lights are ideal for all types of location lighting.
HMI Par Series Light is available in two sizes of GL-PAR M18 and GL-PAR M40. The M18 is an 1,800W open face lamphead and is adjustable from 20° to 60° without requiring spreader lenses.
2. FEATURES:
- Classic and durable design.
- Fully Aluminum light house.
- Polyhedral Improved reflector, Converging more light.
- Standby hot start, universal ballast for 2500/4000/M40.
- flicker-free High Speed Electronic Ballasts.
3. DETAIL OF PRODUCTS:
- Lens snap, easy to open and install light bulb.
Professional Film Lighting HMI Par Light M40 6000K with Universal Ballast
- Barndoor snap, easy to install
Professional Film Lighting HMI Par Light M40 6000K with Universal Ballast
- Sliding Stirrup.
Professional Film Lighting HMI Par Light M40 6000K with Universal Ballast
- Safe bulb lock
Professional Film Lighting HMI Par Light M40 6000K with Universal Ballast
4. Electronic Ballast Features:

- Universal Ballast for 2500W/4000W/M40.

- High-speed shooting without flick, frequency is 60hz, 75hz, 300hz.

- Stable power output.

- The output light fluctuation is no more than 3%.

- Dimming range 50%-100%, stepless dimming.

- The intensity of light increases by at least %5 compared to inductive ballasts.

- Lamp life is extended by at least 20%.

- Compared with inductive ballasts, it has a smaller volume and weight.
5. Univeral Ballast Specification:

Ballast Type: Electronic ballast (NO DMX )
Ballast power: 2500/4000 Watts
Supply Voltage: 220-250V /AC 50/60Hz L,N,PE
frequency mode: optional 50Hz/ 60Hz/ flicker-free
Lamp Power: 2500W-4000W (constant control)
Current Characteristic: square wave,75Hz
Dimming Range: 100% - 50%
Nominal Lamp Power Starting Cold Start and Hot Re-strike
Typical Light Ripple: Typ. <3%
Power Cable: 1.5m
Protection Class: IP32
Material: Metal Housing
Weight: 20 kg
Dimensions (H x W x L): 243x370x450 mm
6.SUPPLIED WITH:

- M40 HMI Lamphead ( OSRAM bulb does not included and local purchasing suggested)
- 2.5/4.0/M40 High Speed Electronic Ballast Ballast
- 6M HEAD-TO-BALLAST CABLES
- 4-leaf Barndoor
- Slim Yoke with tilt lock
