Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Specifications
Application :
Indoor
Type :
LED
Color :
Full color
Panel Size :
250mm*250mm, 250mm*250mm
Supplier Type :
ODM, OEM
Place of Origin :
Guangdong, China
Model Number :
C2-2.9I
Brand Name :
TEWEI
use :
stage, Wedding, meeting, Concert
Pixel Pitch :
2.9mm, 2.9mm
Specification :
Video Wall
Touch Screen Type :
\
Brightness :
1000 cd/㎡, 1000 cd/㎡
Lifespan (hours) :
100000, 100000
IP Rating :
IP31, IP31
HS Code :
8528591090
Resolution :
\
View Angle（H/V） :
140°, 140°
Product name :
Led Video Display Panel
Certificate :
CE ROHS FCC
Warranty :
2years
Packaging Details :
Flight Case
Supply Ability :
4000 Set/Sets per Month
Price :
$235.00/sets 1-49 sets
Description
Products Description
Indoor
Model
C2 Series P1.9
C2 Series P2.6
C2 Series P2.9
C2 Series P3.9
LED Type
SMD1515
SMD1515
SMD2121
SMD2121
Physical Density(Dot/sqm)
262144
147456
112896
65536
Module Resolution
128*128
96*96
84*84
64*64
Module Size (W*H)
250*250
250*250
250*250
250*250
Panel Dimension (W*H*D )
500*500*80
500*500(1000) *80
500*500(1000) *80
500*500(1000)*80
Panel Resolution (Dot/sqm)
256*256
192*192 / 192*384
168*168 / 168*336
128*128 / 128*256
Module Qty per Cabinet
2*2
2*2 / 2*4
2*2 / 2*4
2*2 / 2*4
Panel Weight (kg/Panel)
7.5
7.5 / 12.5
7.5 / 12.5
7.5 / 12.5
Grey Level
≥16bit / 65536 level
≥16bit / 65536 level
≥16bit / 65536 level
≥16bit / 65536 level
Maintenance Mode
Front/ rear Maintenance
Front/ rear Maintenance
Front/ rear Maintenance
Front/ rear Maintenance
Cabinet Frame
Die-casting Aluminum
Die-casting Aluminum
Die-casting Aluminum
Die-casting Aluminum
Brightness (CD/㎡)
≥1000
≥1000
≥1000
≥1000
Color Temperature (K)
3200-9300 0ptional
3200-9300 0ptional
3200-9300 0ptional
3200-9300 0ptional
Viewing Angle (H/V)
160° /160°
160° /160°
160° /160°
160° /160°
The Optimal Viewing Distance
2-50M
3-50M
3-100M
4-100M
Display Color
68.7 billion
68.7 billion
68.7 billion
68.7 billion
Contrast Ratio
5000:01:00
5000:01:00
5000:01:00
5000:01:00
Frame Frequency (Hz)
50 & 60
50 & 60
50 & 60
50 & 60
Drving Mode
1/32 Scan
1/32 Scan
1/32 Scan
1/32 Scan
Video Effffect
Video Sync
Video Sync
Video Sync
Video Sync
Control Mode
2K，4K
2K，4K
2K，4K
2K，4K
Protection Degree
IP31
IP31
IP31
IP31
Maximum Power Consumption
600W/㎡
600W/㎡
600W/㎡
600W/㎡
Average Power Consumption
200-300W/㎡
200-300W/㎡
200-300W/㎡
200-300W/㎡
Outdoor
Model
C2 Series P2.6
C2 Series P2.9
C2 Series P3.9
C2 Series P4.8
LED Type
SMD1415
SMD1415
SMD1921
SMD1921
Physical Density(Dot/sqm)
147456
112896
65536
43264
Module Resolution
96*96
84*84
64*64
52*52
Module Size (W*H)
250*250
250*250
250*250
250*250
Panel Dimension (W*H*D )
500*500*83
500*500(1000) *83
500*500(1000) *83
500*500(1000)*83
Panel Resolution (Dot/sqm)
192*192
168*168 / 168*336
128*128 / 128*256
104*X104/104*208
Module Qty per Cabinet
2*2
2*2 / 2*4
2*2 / 2*4
2*2 / 2*4
Panel Weight (kg/Panel)
8.5
8.5/13.5
8.5/13.5
8.5/13.5
Grey Level
≥16bit / 65536 level
≥16bit / 65536 level
≥16bit / 65536 level
≥16bit / 65536 level
Maintenance Mode
rear Maintenance
rear Maintenance
rear Maintenance
rear Maintenance
Cabinet Frame
Die-casting Aluminum
Die-casting Aluminum
Die-casting Aluminum
Die-casting Aluminum
Brightness (CD/㎡)
≥5000
≥5000
≥5000
≥5000
Viewing Angle (H/V)
160° /160°
160° /160°
160° /160°
160° /160°
The Optimal Viewing Distance
3-50M
3-100M
4-150M
4-150M
Display Color
68.7 billion
68.7 billion
68.7 billion
68.7 billion
Contrast Ratio
5000:01:00
5000:01:00
5000:01:00
5000:01:00
Frame Frequency (Hz)
50 & 60
50 & 60
50 & 60
50 & 60
Drving Mode
1/32 Scan
1/28Scan
1/16 Scan
1/13Scan
Protection Degree
IP65
IP65
IP65
IP65
Maximum Power Consumption
800W/㎡
800W/㎡
800W/㎡
800W/㎡
Average Power Consumption
200-300W/㎡
200-300W/㎡
200-300W/㎡
200-300W/㎡
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Details Images
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Company Profile
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Certifications
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
Product packaging
Indoor Video Advertisement Wall-Mounted LED Display Screen with P2.9 Pixel Pitch
FAQ
Q1. Can you produce according to samples? A: Yes, we can produce according to your samples or technical drawings. We can manufacture molds and fixtures. Q2: What is your best service? 1: One-to-one sales engineer responsible for customers; 2. Understand your project and provide the best solution for it;, 3. Track your order, let you know every step and detail of the order; 4. Teach you how to install and use the screen; 5. Care about the follow-up use of your screen and ensure your after-sales service is good. Q3. What is your packing condition? A: Usually, we pack our goods in neutral wooden cases and flight cases. If you have a legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters. Q4. What are your payment terms? A: T/T, 30% as deposit, 70% before delivery. We will show you the photos of the products and packages before you pay the balance. Q5: How about your warranty period? Answer: 2 years warranty. Structural design, installation issues, system issues, how to use the screen... Don't worry, we have a professional after-sales team to solve any problems for you after placing the order. Your dedicated sales engineer will also help you with any issues.
