Municipal Led Street Light 100 Watt 220 – 240 Volts Ip65 120 Watt 200 Watt
Municipal Led Street Light 100 Watt 220 – 240 Volts Ip65 120 Watt 200 Watt
Municipal Led Street Light 100 Watt 220 – 240 Volts Ip65 120 Watt 200 Watt
Municipal Led Street Light 100 Watt 220 – 240 Volts Ip65 120 Watt 200 Watt
Municipal Led Street Light 100 Watt 220 – 240 Volts Ip65 120 Watt 200 Watt
Municipal Led Street Light 100 Watt 220 – 240 Volts Ip65 120 Watt 200 Watt
Municipal Led Street Light 100 Watt 220 – 240 Volts Ip65 120 Watt 200 Watt
Municipal Led Street Light 100 Watt 220 – 240 Volts Ip65 120 Watt 200 Watt
Municipal Led Street Light 100 Watt 220 – 240 Volts Ip65 120 Watt 200 Watt
Municipal Led Street Light 100 Watt 220 – 240 Volts Ip65 120 Watt 200 Watt
Specifications
Brand Name :
Coursertech
Model Number :
LDLED-03801
Place of Origin :
CHINA
MOQ :
100
Price :
90USD
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
20000sets a month
Delivery Time :
20-25 work days
Packaging Details :
CARTON
Product size :
Customizable
Net weight :
Customizable
Material :
Iron and aluminium
Color :
White,Red,Blue,Green and Black
Lumen :
160lm/w
Voltage :
100-240V
IP grade :
IP65
Working life :
＞80000HRS
CCT :
3000-4500K
Central Illumination :
47lux(10m)
Description

LED Street Light Increase The Luminous Surface, Eliminate Glare, Sublimate The Visual Effect

Municipal Led Street Light 100 Watt 220 – 240 Volts Ip65 120 Watt 200 WattMunicipal Led Street Light 100 Watt 220 – 240 Volts Ip65 120 Watt 200 WattMunicipal Led Street Light 100 Watt 220 – 240 Volts Ip65 120 Watt 200 WattMunicipal Led Street Light 100 Watt 220 – 240 Volts Ip65 120 Watt 200 WattMunicipal Led Street Light 100 Watt 220 – 240 Volts Ip65 120 Watt 200 Watt

1.Brand new innovation patent light design,the 11° deviation angle design for the portrait light curve,
which is the first one in the domestic,make more light towards to the middle of the road.
And the transversal light angle is 135°with the 0.65 regularity to avoid the dark area radically.

Parameter
/Item No.		 JMJX-30 JMJX-60 JMJX-90 JMJX-120 JMJX-150
Rated Power 30W 60W 90W 120W 150W
LED Chip 3W/pc 3W/pc 3W/pc 3W/pc 3W/pc
LED Quantity 24 48 72 96 120
Color Temperature 4500-5500K 4500-5500K 4500-5500K 4500-5500K 4500-5500K
Input Voltage AC100-260V AC100-260V AC100-260V AC100-260V AC100-260V
Frequency Range 50-60Hz 50-60Hz 50-60Hz 50-60Hz 50-60Hz
Power Factor >0.97 >0.97 >0.97 >0.97 >0.97
LED
Luminous Efficiency		 140lm/w 140lm/w 140lm/w 140lm/w 140lm/w
(%)
Lamp's Efficiency		 >92% >92% >92% >92% >92%
IP Grade IP65 IP65 IP65 IP65 IP65
Working life >80000HRS >80000HRS >80000HRS >80000HRS >80000HRS

Environment Temperature		 -30℃to+65℃ -30℃to+65℃ -30℃to+65℃ -30℃to+65℃ -30℃to+65℃
Light Body material Aluminium Aluminium Aluminium Aluminium Aluminium
Pole Height 6m 7m 9m 10m 12m
Central Illumination 40lux(6m) 55lux(7m) 48lux(9m) 47lux(10m) 40lux(12m)
Pole Distance 25M 35M 40M 45M 50M
Installing Size Φ61mm Φ61mm Φ61mm Φ61mm Φ61mm
Products Size 520*380*120mm 600*380*120mm 720*380*120mm 840*380*120mm 960*380*120mm
Packing Size 580*445*185mm 660*445*185mm 780*445*185mm 900*445*185mm 1020*445*185mm
Net Weight 8KG 10KG 12KG 14KG 16KG
Gross Weight 10KG 12KG 14KG 16KG 18KG

The biggest feature of LED for lighting is that it has the function of directional light emission, because almost all power LEDs are equipped with reflectors, and the efficiency of this reflector is significantly higher than that of lamps. In addition, the efficiency of its own reflector has been included in the light effect detection of LED. For road lamps using LED, the directional emission characteristics of LED should be used as much as possible, so that each LED in the road lamps can directly shoot the light to each area of the illuminated road surface, and then use the auxiliary light distribution of the lamp reflector to achieve a very reasonable comprehensive light distribution of road lamps. In the actual design of road lighting lamps, on the premise of basically setting the shooting direction of each LED, each LED can be fixed on the lamps with spherical universal joint. When the lamps are used in different heights and irradiation widths, the irradiation direction of each LED can achieve satisfactory results by adjusting the spherical universal joint.
