Led street light outdoor lighting 140lm/w 5years warranty
Relying on the conception of "be Vigilant in Peace Time,Science and Technology Innovation",our company cooperates
with Beijing Kedian Microwave Electronic Co.,Ltd.,which belongs to the Institute of Electronic of Chinese Academy of
Sciences,we together built Zhejiang Coursertech Optoelectronics Co.,Ltd.Depending on the technical strength of Chinese
Academy of Sciences,with advanced production equipments and high-quality imported electrical components,we
successfully develop and manufacture two series products:
1 | Rated Power | 80-150w | 200-250w |
2 | LED Chip | 5W/pc | 5W/pc |
3 | LED Quantity | 88 | 132 |
4 | CCT | 3500K-4500K | 3500K-4500K |
5 | Voltage | AC100-265V | AC100-265V |
6 | Frequrncy Range | 50-60Hz | 50-60Hz |
7 | Power factor | 0.975 | 0.975 |
8 | Lumen | 150lm/w | 150lm/w |
9 | Total lumen | 12000lm | 30000lm |
10 | IP | IP65 | IP65 |
11 | Working life | >80000HRS | >80000HRS |
12 | Environment Temperature | -30℃to+65℃ | -30℃to+65℃ |
13 | Light Body material | Aluminium | Aluminium |
14 | Pole Height | 10-12m | 12m |
15 | Installing Size | Φ61mm | Φ61mm |
16 | Products Size | 885*361*166mm | 1053*379*174mm |
17 | Packing Size | 900*380*190mm | 1070*400*180mm |
18 | Net Weight | 15KG | 24KG |
19 | Gross Weight | 16.5KG | 26KG |
The biggest characteristic of LED for lighting is the function of directional emission light, because almost all power LED are equipped with reflectors, and the efficiency of such reflectors is significantly higher than the reflector efficiency of lamps.In addition, the LED has includes the efficiency of its own reflector.The road lamps using LED should make use of the directional emission characteristics of LED as far as possible, so that each LED in the road lamps directly shoots the light to each area of the road surface, and then use the auxiliary light distribution of the lamp reflector to achieve a very reasonable comprehensive light distribution of road lamps.In the actual design of road lighting fixtures, each LED is fixed on the lamp with the basic illumination direction of each LED. When the lamp is used at different heights and irradiation width, the illumination direction of each LED can achieve the satisfactory result.
