High Efficiency 20 W Integrated Solar Street Light With Dimming Functions
High Efficiency 20 W Integrated Solar Street Light With Dimming Functions
High Efficiency 20 W Integrated Solar Street Light With Dimming Functions
High Efficiency 20 W Integrated Solar Street Light With Dimming Functions
Specifications
Place of Origin :
China, shenzhen
Brand Name :
NOMO LED
Certification :
CE, UL,FCC, ISO, ROHS,SAA
Model Number :
PVNST20B
MOQ :
1
Packaging Details :
Carton
Delivery Time :
Within 15 working days
Payment Terms :
T/T, L/C, Western union
Supply Ability :
100000000sets
Description
Detailed Product Description
Product Type: Solar LED Street Lights LED Number: 10Units
Nominal Power: 20W Battery Spec: 16.5AH/12V
Solar Panel Spec.: Monocrystal 37.8W /18V Switch Lights Sense Threshold: On<=10Lxs,off >=15Lxs
Luminous Flux: 2200lm Light Type:
CCT: 3000K Or 4000K Or 5000K Or 5700K Warranty: 3 Years

High Efficiency 20 W Integrated Solar Street Light With Dimming Functions

Overview

A new revolutionary product combining solar and LED technology. The best solution for all these areas that

doesn´t have electric supply, remote places with no good communications, and all the areas with electricity supply but with good climatology. The system charges the battery during the day and illuminates at night.

Due to the use of LED technology, it is able to maximize all the solar energy and illuminate the environment

with radiant light.

Application

Garden, Residence, Courtyard

Areas with difficult communications

All areas with good climatology

Areas with no electrical supply

Specifications
Model PVNST20B
LED Number 10units
Nominal Power 20W
Battery Spec. 16.5AH/12V
Solar Panel Spec. Monocrystal 37.8W /18V
LED Brand LG
Luminous Flux 2200lm
Light type 1s,2s
CCT 3000K.4000K.5000K.5700K
Charge time 5-6 hours
Worktime at Energy
-saving Model(25%)		 more than 35 hours
Discharge Temperature -20℃~+60℃
Charge temperature <60℃
Switch Lights Sense
Threshold		 on<=10Lxs,off >=15Lxs
mounting height 4-5m
space between light 18m
Pole Diamerter Fixture 40-60mm
warranty period 3 years
Packing Details
Fixture Dimension 969 x301 x88 mm/38.1x11.9x3.5inches
Fixture Weight 7.9kg /21.4 lbs
Packing Dimension 1010 x360 x145 mm/39.8x14.2x5.7inches
Packing Weight 12.0kg /26.5 lbs

High Efficiency 20 W Integrated Solar Street Light With Dimming Functions

High Efficiency 20 W Integrated Solar Street Light With Dimming Functions

Advantage Of Lithium-Iron Battery

One important advantage over other lithium-ion chemistries is thermal and chemical stability, which improves battery safety. LiFePO4 is an intrinsically safer cathode material than LiCoO2 and manganese spinel.The

Fe-P-O bond is stronger than the Co-O bond, so that when abused, (shortcircuited, overheated, etc.) the

oxygen atoms are much harder to remove. This stabilization of the redox energies also helps fast ion migration.

High Efficiency 20 W Integrated Solar Street Light With Dimming Functions

AFTER-SALE SERIVCE

3 YEARS WARRANTY

*Damage by thunderstroke over 4KV(L,N against FG) /2KV(L against N) will not covered by warranty.
