Full Color Led Display For Advertising P5 Led Video Wall Panel Led Screen Indoor
Product Description
1. With the high quality raw material, mature process and scale production,the quality is ensured.
2. Full color Led display for advertising leader, very mature product. Initial creator for such panel, light-proof. Super slim, light weight, can meet the most demanding requirements.
3. Ideal for indoor advertisement media, government& enterprise project culture & tourism, sports, propaganda Image, commercial real estate.
4. We have many models : P4 ,P5, P6, P8, P10 . The definition and prices differ a lot . You can choose based on the installation environment and your budget .
5. Support point correction function, ensure the consistency of the color and the brightness in the process of use.
6. We have the most competitive prices based on all good material we use . Our quality is very repliable and we win very good reputation in the market.
7. The appearance of Led screen indoor is very simple and elegant,looks very high end.
Technical Prameters of P5 Led Video Wall Panel
Pixel pitch | 5mm |
Pixel Configuration | 1R1G1B |
LED component | SMD3528 |
Size of module | 320mm x 160mm |
Resolution of module | 64x32 |
Size of cabinet | 960mm x 960mm x 110mm |
Resolution of cabinet | 192x192 |
Material of Cabinet | Iron |
Brightness | >1200cd/sqm |
Best viewing distance | 5-30M |
Maximum power consumption | 440W/sqm |
Average power consumption | 190W/sqm |
Driving method | 1/16scan |
Control method | Synchronization |
Gray scale | 65536 |
Color temperature | 3200-9300k |
Uniformity | 97% |
Working voltage | AC220V/110V±10% |
Working temperature | -20ºC~+50ºC±10% |
Working humidity | 10% ~ 90% |
MTBF | 10,000 hours |
Frame frequence | 50/60Hz |
Refresh frequence | >1920Hz |
IP grade | IP30 |
Life Span | 100,000 hours |
Data transafer method | RJ45 |
Pratical standard | CCC TUV-CE ETL etc. |
Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. |
Systems operating platform | WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development |
Q1:LED display models are generally expressed in PX, such as P2 P3 P4....P8 P10.What does this mean?
A: P2 P3 P4.....P8 P10 means the pixel pitch is 2mm 3mm 4mm....8mm 10mm,which determines the number of pixels per unit area of a display. So it represents the clarity of the display. The smaller the pitch, the higher the clarity. Usually, the models of indoor full color display are P1.875,P2.5,P3,P4,P5. Outdoor full color display are P4,P5,P6,P8,P10.
Q2:Can I order a sample?
A:Yes.We welcome customers to order sample to check the quality and service.
Q3:Is it OK to print my LOGO on your product?
A:Yes.We support OEM and ODM service.
Q4:How about your quality?
A:The quality of our display is excellent. We use the materials of high quality suppliers, strictly control the production process. and pass the multiple quality inspection to ensure every product is qualified.
Q5:What about the warranty?
A:Three year warranty
