Specifications
Brand Name :
Singheng
Model Number :
P5
Certification :
CE RoHS UL Certifications
Place of Origin :
China (Mainland)
MOQ :
1 square meter
Price :
USD+To be negotiated+square meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
3000+square meter+per month
Delivery Time :
About 16 days
Packaging Details :
Plywood case
Application :
Video
Pixel Density :
40000 dots/sqm
Pixel Configuration :
1R1G1B
Working voltage :
AC220V/110V±10%
Working temperature :
-20ºC~+50ºC±10%
MTBF :
10,000 hours
Frame frequency :
50/60Hz
Refresh frequency :
>1920Hz
Data transafer method :
RJ45
Pratical standard :
CCC TUV-CE ETL etc
Description

Large Advertising Screens Led Wall Panels P5 Full Color Led Display Screen

  • Product Description

1. High contrast rate up to 5000:1 by using black LED.

2. The appearance of led display is very simple and elegant,looks very high end.

3. 14 bit color,16384 gray scale,showing very clear and vivid video and images.

4. Good thermal design, excellent heat dissipation even no fan installation.

5. Led wall panels module, excellent display effect,broadcast color gamut, intelligent adjustment for color temperature and brightness. Uniform color, high contrast, the picture is vivid and nature.

6. Large advertising screens, fast installation for modules, meets indoor naked installtion requirements. Design based on module, which saves installation and maintenance cost, fast speed, maintenance with power on.

7. Support point correction function, ensure the consistency of the color and the brightness in the process of use.

8. We have the most competitive prices based on all good material we use . Our quality is very repliable and we win very good reputation in the market.

  • Technical Prameters​ of P5 Full Color Led Display Screen

Pixel pitch 5mm
Pixel Configuration 1R1G1B
LED component SMD3528
Size of module 320mm x 160mm
Resolution of module 64x32
Size of cabinet 960mm x 960mm x 110mm
Resolution of cabinet 192x192
Material of Cabinet Iron
Brightness >1200cd/sqm
Best viewing distance 5-30M
Maximum power consumption 440W/sqm
Average power consumption 190W/sqm
Driving method 1/16scan
Control method Synchronization
Gray scale 65536
Color temperature 3200-9300k
Uniformity 97%
Working voltage AC220V/110V±10%
Working temperature -20ºC~+50ºC±10%
Working humidity 10% ~ 90%
MTBF 10,000 hours
Frame frequence 50/60Hz
Refresh frequence >1920Hz
IP grade IP30
Life Span 100,000 hours
Data transafer method RJ45
Pratical standard CCC TUV-CE ETL etc.
Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.
Systems operating platform WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development

  • FAQ

Q1:What pixel pitch should I choose on my display?
A:Using the PX screen, it is determined mainly by the viewing distance, the size of the screen, the desired effect and the customer budget. It is generally believed that P5 is suitable for watching outside 5 meters. P10 is suitable for watching outside 10 meters. Of course, this data is not very accurate, and the customer can just refer to it. It also depends on the size of the screen, generally it is considered that more than 100 thousand pixels for a full color display then have a standard effect.

Q2:How about your quality?
A:The quality of our display is excellent. We use the materials of high quality suppliers, strictly control the production process. and pass the multiple quality inspection to ensure every product is qualified.

Q3:What about the warranty?
A:Three year warranty.

Q4:What about the lead time?
A:Orders less than 50 square meters display ,lead time is 16 days.

Q5:How long is the transportation time?
A:Shipping:20-30 days.Airlift:3-7 days
