65536 Grey Scale Advertising Led Display Screen P10 With Aluminum Cabinet
65536 Grey Scale Advertising Led Display Screen P10 With Aluminum Cabinet
65536 Grey Scale Advertising Led Display Screen P10 With Aluminum Cabinet
65536 Grey Scale Advertising Led Display Screen P10 With Aluminum Cabinet
Specifications
Brand Name :
Singheng
Model Number :
P10--OD
Certification :
CE,ROHS,FCC,ISO9001
Place of Origin :
SHENZHEN China
MOQ :
1 piece
Price :
USD+to be negotiated+piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
3000+square metre+per month
Delivery Time :
About 16 days
Packaging Details :
Plywood case
Pixel Pitch :
10 mm
Pixel Density :
10000 dot/sqm
Pixel Configuration :
1R1G1B SMD3535
Module Size :
320*160 mm
Cabinet type :
opened/closed
Max Power Consumption :
750 w/sqm
Average Power Consumption :
350 w/sqm
Control Distance :
optical fiber≤500m, Single mode optical
Signal Transmission Mode :
568B
Description

outdoor video display screens led display cost P10 Aluminum cabinet

P10 OUTDOOR FULL-COLOR TECHNICAL PARAMETER
Item Parameter
Pixel Pitch 10 mm
Pixel Density 10000 dot/sqm
Pixel Configuration 1R1G1B SMD3535
Module Size 320*160 mm
LED brand R&G&B: EPISTAR
Cabinet type opened/closed
Unit cabinet dimension 960mm×960mm×140mm
Module Resolution 32*16 dot
Cabinet Resolution 96*96 dot
Weight 35KG
Cabinet Material SPCC
Viewing Distance ≥10 m
Viewing Angle (Horizontal Axis) 160°
Viewing Angle (Vertical Axis) 160°
Refresh Rate ＞1920Hz
Grey Scale 65536
Brightness ≥6000cd/m2
Max Power Consumption 750 w/sqm
Average Power Consumption 350 w/sqm
Drive Mode 1/4 Scan Constant Current
Signal EMC VGA,DVE,
Signal Transmission Mode 568B
Network Cable ≤100m, Multimode
Control Distance optical fiber≤500m, Single mode optical
fiber ≤20 kilometer
Lifespan ≥10,0000 h
Waterproof Grade Outdoor Use IP65
Input Voltage AC220V±10% 50-60HZ
Celsius Degree:—10℃-40℃
humidity:10 10—85%RH

1. Accurate, shortcut, flexile installation, can be applied to any different installation environment.

2.With the protection rating of IP65, face any bad weather.

3. Complete series, customized to satiny any requirements of customers

4.With the professional aviation plug as the connectors ensure the quality and safety.

5.With the high quality raw material, mature process and scale production,the quality is ensured.
6. Outdoor HD LED display leader, very mature product. Initial creator for such panel, light-proof. Super slim, light weight, can meet the most demanding requirements.

7. Outdoor LED display module, excellent display effect,broadcast color gamut, intelligent adjustment for color temperature and brightness. Uniform color, high contrast, the picture is vivid and nature.

outdoor video display screens led display cost P10 Aluminum cabinet

65536 Grey Scale Advertising Led Display Screen P10 With Aluminum Cabinet

65536 Grey Scale Advertising Led Display Screen P10 With Aluminum Cabinet

65536 Grey Scale Advertising Led Display Screen P10 With Aluminum Cabinet

FAQ

Q1:How to install?
A:Free of charge to provide detailed steel structure drawings and installation guidance, wiring diagram and free remote debugging .We can also send our engineers to the site to guide the installation.

Q2:How about your quality?
A:The quality of our display is excellent. We use the materials of high quality suppliers, strictly control the production process. and pass the multiple quality inspection to ensure every product is qualified.

Q3:What about the warranty?
A:Three year warranty

Q4:What about the lead time?
A:Orders less than 50 square meters display ,lead time is 16 days.

Q5:Can I order a sample?
A:Yes.We welcome customers to order sample to check the quality and service.
