Specifications
Brand Name :
Singheng
Model Number :
P6
Certification :
CE RoHS UL FCC
Place of Origin :
China (Mainland)
MOQ :
1 square meter
Price :
USD+To be negotiated+square meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
3000+square meter+per month
Delivery Time :
About 16 days
Packaging Details :
Flight case
Application :
Video
Pixel Pitch :
6 mm
Pixel Density :
27777 dot/sqm
Pixel Configuration :
1R1G1B SMD2727
Module Size :
192*192 mm
Brightness :
≥6500cd/sqm
Unit cabinet dimension :
576*576
Average Power consumption :
≤550W/sqm
Max Power consumption :
≤1100W/sqm
Screen Dimension :
Customized Size
Description

Led Display Screen Rental Video Wall Rental P6 Led Stage Screen Rental

  • Product Description

1. New structural design is to meet hanging installation and floor installation requirements and can be installed in indoor and outdoor environment

2. The jumbo screen rental cabinets are connected by quick lock. The installation of one cabinet can be completed in 10 seconds.

3. The video wall rental cabinet is light in weight,low installation cost and low power consumption, saving operating costs and reducing labor costs.

4. Support signal line arbitrary connection,meeting the arrangement and placement of different cabinets to create different effects

5. Support brightness adjustment and white balance custom adjustments, allowing screens from different batches to be used together

6. Tailored the most suitable Led display screen rental solution according to customer requirements and on-site environment.

  • Technical parametersof P6 Led Stage Screen Rental

P6 FULL-COLOR RENTAL DISPLAY TECHNICAL PARAMETER
Item Parameter
Pixel Pitch 6 mm
Pixel Density 27777 dot/sqm
Pixel Configuration 1R1G1B SMD2727
Module Size 192*192 mm
LED brand R&G&B: EPISTAR
Cabinet type closed
Protection front:IP65
Unit cabinet dimension 576*576
Module Resolution 32*32 dot
Cabinet Resolution 96*96 dot
Weight 10KG/cabinet
Cabinet Material Die-casting aluminium
Viewing Distance ≥6 m
Viewing Angle (Horizontal Axis) 140°
Viewing Angle (Vertical Axis) 140°
Refresh Rate >1920Hz
Grey Scale 65536
Brightness ≥6500cd/m2
Max Power Consumption 1100 w/sqm
Average Power Consumption 550 w/sqm
Drive Mode 1/8 Scan Constant Current
Signal EMC VGA,DIV,HDMI,SDI
Signal Transmission Mode 568B
Network Cable ≤100m, Multimode
Control Distance optical fiber≤500m, Single mode optical
fiber ≤20 kilometer
Lifespan ≥10,0000 h
Waterproof Grade Outdoor Use Only IP65
Input Voltage AC220V±10% 50-60HZ
Celsius Degree:—10℃-40℃

  • FAQ

Q1:LED display models are generally expressed in PX, such as P2 P3 P4....P8 P10.What does this mean?
A: P2 P3 P4.....P8 P10 means the pixel pitch is 2mm 3mm 4mm....8mm 10mm,which determines the number of pixels per unit area of a display. So it represents the clarity of the display. The smaller the pitch, the higher the clarity. Usually, the models of indoor full color display are P1.875,P2.5,P3,P4,P5. Outdoor full color display are P4,P5,P6,P8,P10.

Q2:What pixel pitch should I choose on my display?
A:Using the PX screen, it is determined mainly by the viewing distance, the size of the screen, the desired effect and the customer budget. It is generally believed that P5 is suitable for watching outside 5 meters. P10 is suitable for watching outside 10 meters. Of course, this data is not very accurate, and the customer can just refer to it. It also depends on the size of the screen, generally it is considered that more than 100 thousand pixels for a full color display then have a standard effect.

Q3: To order a display, what information should l offer you?
A:You should provide width and height of the display, the main usage, the viewing distance, the scene photo and special requirements, then I can provide you a quotation. Sometimes you should also provide information such as geographical location, local climate.

Q4:How to install?
A:Free of charge to provide detailed steel structure drawings and installation guidance, wiring diagram and free remote debugging .We can also send our engineers to the site to guide the installation.


Q5:Can I order a sample?
A:Yes.We welcome customers to order sample to check the quality and service.
