Portable Led Video Wall Stage Rental Led Display P4 Indoor Screens For Hire
11. Support signal line arbitrary connection,meeting the arrangement and placement of different cabinets to create different effects of stage rental Led display
12. Support brightness adjustment and white balance custom adjustments, allowing screens from different batches to be used together
13. High level protection,front side IP65 and back side IP54, suitable for outdoor rental usage
14. Equipped with fly case, it is convenient for storage and transportation and it has good protection for LED display.
4. The color is realistic and the adaptability is strong.
5. Light weight, single-handed, easy to install.
6. The portable Led video wall cabinet is formed by die-casting aluminum, which has high strength, strong toughness, high precision,and it is difficult to be deformed.
Technical parameters of P4 Indoor Screens For Hire
Unit Module | Item | Parameter |
Model Number | P4-16S | |
Module size | 256mm*128mm | |
Module thickness | 14.27mm | |
Pixel pitch | 4mm | |
Pixels Density | 62500 dots/sqm | |
Pixel configuration | 1R1G1B | |
LED Package mode | SMD2121 | |
Pixel resolution | 64dots(W)*32dots(H) | |
Max Power | 23W | |
Module thickness | 14.27mm (without magnet) | |
29.33mm (within magnet) | ||
Weight | 0.210kg | |
Drive type | Constant drive | |
Scan mode | 1/16scan | |
Port type | HUB75-A | |
Brightness of white balance | ≥1200cd/sqm |
LED Cabinet | Dimension | 512mm*512mm |
Monomer Module Number | 8pcs | |
Power supply | 5V/60A*1 pcs | |
Pixel per cabinet | 128*128 | |
Best viewing distance | 4M~30M | |
Best viewing angle | 160°(W) 140°(H) | |
Temperature | storage:-45℃~+85℃ working:-40℃~+50℃ | |
Relative humidity | 10%-95% | |
Thickness | 85mm |
Q1:LED display models are generally expressed in PX, such as P2 P3 P4....P8 P10.What does this mean?
A: P2 P3 P4.....P8 P10 means the pixel pitch is 2mm 3mm 4mm....8mm 10mm,which determines the number of pixels per unit area of a display. So it represents the clarity of the display. The smaller the pitch, the higher the clarity. Usually, the models of indoor full color display are P1.875,P2.5,P3,P4,P5. Outdoor full color display are P4,P5,P6,P8,P10.
Q2: To order a display, what information should l offer you?
A:You should provide width and height of the display, the main usage, the viewing distance, the scene photo and special requirements, then I can provide you a quotation. Sometimes you should also provide information such as geographical location, local climate.
Q3:What about the lead time?
A:Orders less than 50 square meters display ,lead time is 16 days.
Q4:Can I order a sample?
A:Yes.We welcome customers to order sample to check the quality and service.
Q5:Is it OK to print my LOGO on your product?
A:Yes.We support OEM and ODM service.
