Specifications
Brand Name :
BST
Model Number :
BST-IF2.5
Certification :
CE,FCC, CCC, Rohs,ISO
Place of Origin :
China
MOQ :
1sqm / Piece
Price :
Negotiation
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
5000sqm per month
Delivery Time :
7 - 20 days
Packaging Details :
wooden case
Warranty :
2years
Driving method :
1/16 scan, constant current
Package :
Wooden case
Brightness :
800nits /sqm
Cabinet Size :
480X480mm
Module Size :
240X240mm
Description

Lightweight P2.5 SMD2121 Indoor Full Color Led Screen With 140° H / 140° V viewing angle

Products Feature:
1. Light Weight:Using aluminum profile material, the cabinet weight is only 7 kg.
2. High Contrast Ratio: novel design of mask,contrast ratio can reach 1800.
3. Quiet:Direct current fan only has little noise
4. Thin:the thickest part of cabinet is only 65mm.
5. High Precision:each cabinet of precision deviation <0.2mm.
6. High Refreshing:Usually it can reach 800Hz,but it can reach 1800Hz if you use appropriative IC.
7. Convenient and Fast Installation.
8. Best Cabinet Size: 480mm*480mm.
9. Maintenance principles: response in time, solve problems as soon as possible and ensure the use.
10. Maintenance terms: In the Maintenance period, free of all maintenance charges. Under normal use and storage,our company will be responsible for the equipments. If there is any failure in product quality, our company will maintain and change the components for free. After Maintenance period, only charge the material costs fees free of manual work fees
Lightweight P2.5 SMD2121 Indoor Full Color Led Screen With 140° H / 140° V viewing angle
Applications:

Wide Applicability: Stage rental events, entertainment, indoor and outdoor environment.


Specification:

BST-IF2.5mm Spec

Pixel Pitch (mm)

2.5

LED Type

SMD

Pixel Density (pixel/sq.m.)

277008

Viewing Angle (H/V)

140° / 140°

Brightness(cd/sq.m.)

1000

Refresh Rate(Hz)

1920~4800

Optimized Viewing Distance (m)

2.5~30

Average Power Consumption (W/sq.m.)

272

Max. Power Consumption (W/sq.m.)

680

Input Voltage

AC110V or AC220V±10% 50/60Hz

Module Size in Pixel (W×H)

96×96

Module Size in mm (W×H)

240×240

Panel Size in Pixel (W×H)

480×480

Panel Size in mm (W×H×D)

480×480×80

Weight (kg/Panel.)

7

IP Rating

IP40

Maintenance

Rear

Operating Temperature

-10℃ ~40℃

Operating Humidity

10~80RH%



Ultral HD P2.5mm indoor full color LED Display
Lightweight P2.5 SMD2121 Indoor Full Color Led Screen With 140° H / 140° V viewing angle
Lightweight P2.5 SMD2121 Indoor Full Color Led Screen With 140° H / 140° V viewing angle
Lightweight P2.5 SMD2121 Indoor Full Color Led Screen With 140° H / 140° V viewing angle
Lightweight P2.5 SMD2121 Indoor Full Color Led Screen With 140° H / 140° V viewing angleLightweight P2.5 SMD2121 Indoor Full Color Led Screen With 140° H / 140° V viewing angleLightweight P2.5 SMD2121 Indoor Full Color Led Screen With 140° H / 140° V viewing angle


FAQ

1. How can i place an order?

Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time.
1)It will use for what ?
2)where will you install it ?
3)full color or single color?
4)It's rental installation or fixed installation ?
For designing or further discussion, it is better to contact us with Skype, in case of any delays.

2. What kind of display we provide?
We have indoor/outdoor/led curtain/mobile LED /rental LED display/LED stage/LED DanceFloor/Irregular LED display for you choose.

3. What about the lead time for order ?
Always: 15-20 working days

4.How about the warranty?
We have 2years warranty and lifelong maintenance

5. What is your terms of delivery?
We accept EXW, FOB, CFR, CIF, DDU, DDP, etc. You can choose the one which is the most convenient or cost effective for you.
