High Rsolution P2.5 Black LEDs Display Module 240 × 240mm for Commercial Advertising
High Rsolution P2.5 Black LEDs Display Module 240 × 240mm for Commercial Advertising
High Rsolution P2.5 Black LEDs Display Module 240 × 240mm for Commercial Advertising
High Rsolution P2.5 Black LEDs Display Module 240 × 240mm for Commercial Advertising
High Rsolution P2.5 Black LEDs Display Module 240 × 240mm for Commercial Advertising
High Rsolution P2.5 Black LEDs Display Module 240 × 240mm for Commercial Advertising
Specifications
Brand Name :
BST
Model Number :
BST-IM-2.5
Certification :
CE, RoHS, FCC, ISO
Place of Origin :
Shenzhen, China
MOQ :
negotiable
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5000sqm/month
Delivery Time :
10-20 days after receive payment
Packaging Details :
Carton case, Plywood case ;
Type :
P2.5mm
Drive Method :
1/24 scan
View Angle :
140 degree (H/V)
Size :
240X240mm
Package :
carton case
Hub Type :
Hub75
Description

High Rsolution P2.5 Black LEDs Display Module 240 × 240mm for Commercial Advertising​


Quick Detail:
1, First class LED chip
2, Good quality; Good Price
3. 240× 240 mm module size;
4. SMD2121 Black LEDs;
5. 1/24 scan constant current;
6, Fast delivery time.

Detail Description:
This LED module is with low power consumption, about 300 W per square meter;
Each square meter brightness could reach to 1300 nits;
Synchronization control method operated to achieve higher refresh rate.

Specifications:

Product model number

BST-IM-2.5

1.Pixel

Pixel L ED

2121

Pixel Configuration

1 R, 1G , 1B

Wave length ( nm )

R: 626-628 , G: 518-520 , B: 466-468

Pixels Pitch ( mm )

2.5

2 . Module

Module Size ( mm )

240 * 240 * 10

Module Pixels (dot)

96 * 96

3.Packaging

Packing box material

Wooden case or Carton case

4.electricity parameter

Pixel density (dots/ m 2 )

160000

White Balance Brightness ( cd/m 2 )

≥ 1300

Color temperature ( K )

5000-9500 (choice by user)

Brightness Adjusted

100 grade by software or by Auto-optic induced.

View Angel

Horizontal 140 ° ; Vertical 140 °

Best viewing distance ( m )

2.5-30

Communication distance ( m )

Internet Wire : 120 Fiber Cable : 1000

Screen work Method

1/24 scan

LED driving method

Constant driving current

Gray Grades

16384 levels for each color

Refresh Frequency ( Hz )

≥ 1500

Picture display method

Dots to dots display synchronized with CRT

Signal interface

DVI

Input signal

Video : PAL/NTSC optioned . VGA, Svideo, DVD, TV

Display format

800 * 600 , 1024 * 768 , 1280 * 1024

Software

Support windows series system

Working temperature (ºC )

-30+60

Humidity ( RH )

Up to 95

Stored temperature ( ºC)

-30 +70

Screen Lifetime(hours)

≥100, 000

Out of controlled dots

≤3/10, 000 (Out of controlled dots means the pixels
of which the brightness
and the wave length are both >10%
depart to the normal one)

Switch power supply

Switch power supply
(include CE/GS or UL/CSA certificate)
110V/60HZ , 220V/50HZ


High Rsolution P2.5 Black LEDs Display Module 240 × 240mm for Commercial AdvertisingHigh Rsolution P2.5 Black LEDs Display Module 240 × 240mm for Commercial Advertising

Packing and Shipment
High Rsolution P2.5 Black LEDs Display Module 240 × 240mm for Commercial Advertising
High Rsolution P2.5 Black LEDs Display Module 240 × 240mm for Commercial Advertising
High Rsolution P2.5 Black LEDs Display Module 240 × 240mm for Commercial Advertising


P2.5mm LED Display

High Rsolution P2.5 Black LEDs Display Module 240 × 240mm for Commercial AdvertisingHigh Rsolution P2.5 Black LEDs Display Module 240 × 240mm for Commercial AdvertisingHigh Rsolution P2.5 Black LEDs Display Module 240 × 240mm for Commercial Advertising

Workshop
High Rsolution P2.5 Black LEDs Display Module 240 × 240mm for Commercial Advertising
