Big P5 Front Service Indoor Video Wall Led Display Screen With 140 Degree View Angle
Big P5 Front Service Indoor Video Wall Led Display Screen With 140 Degree View Angle
Big P5 Front Service Indoor Video Wall Led Display Screen With 140 Degree View Angle
Big P5 Front Service Indoor Video Wall Led Display Screen With 140 Degree View Angle
Big P5 Front Service Indoor Video Wall Led Display Screen With 140 Degree View Angle
Big P5 Front Service Indoor Video Wall Led Display Screen With 140 Degree View Angle
Big P5 Front Service Indoor Video Wall Led Display Screen With 140 Degree View Angle
Big P5 Front Service Indoor Video Wall Led Display Screen With 140 Degree View Angle
Specifications
Brand Name :
BST
Model Number :
BST-IFS-5
Certification :
CE, RoHS, FCC, ISO
Place of Origin :
Shenzhen, China
MOQ :
1 pc/ 1 sqm.
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5000sq.meter / Month
Delivery Time :
10-20 day after receive payment
Packaging Details :
Flight case /Fumigation-Free wooden case
Model :
P5
LED Type :
SMD3528
Module Size :
160mmX160mm
Cabinet size :
960mmX960mm
Control Method :
Synchronous Control
Warranty :
2 year
Description

Big P5 Front Service Indoor Video Wall Led Display Screen With 140 Degree View Angle

Quick Detail:

1. Excellent visual effect, better viewing effect for text and graphic or video

2. Large viewing angle,both H/V can reach 140 degree;getting vivid effect within any position of the viewing range;

3. High contrast ratio and good evenness, high uniformity,without mosaic

4. Resist of the high temperature and antioxidation and anti-statiic;

5. Any led in each pixel can be respectively replaced, which reduce the cost of the display maintaince.

6. Long using life & MTBF

Application:

public square, advertising media, sports stadiums, airport station integrated information dissemination, business establishments etc

Description:

1, excellent quality,original epistar chip,MBI driving IC from taiwan


2, Modular design makes the installation and maintance easier.

3, Good anti-corrosion, oxidation resistance, long life span

4. locks on both sides of cabinet contribute to uniformity and flatness of two neighboring cabinets.

5. fast installation, a cabinet could be uninstalled in one minute.

Specifications:

1. Indoor LED Display Technical Parameter

BST-IFS-5 (Pitch 5mm Indoor full color)

Colour temperature

5000~9000 k

Pixel structure

SMD3528, 1R1G1B

Cabinet material

Epoxy paint coated, aluminum / iron

Life span (50% brightness)

100, 000 hrs

Input signal

S-video, RF, RGB, Yuv, YC, composite…

Pixel density

40000 dots/㎡

Luminance

1500cd/㎡

Refresh frequency

≥1500HZ

Module resolution

32 pixel(W) * 32 pixel mm(H)

Cabinet dimension

960mm * 960mm

Cabinet area

0.9216 sq. meter

Malfunction dot rate

1/10000

Optimal visual distance

>6m

Visual angel

140 / 140 degree (H/V)

Max power consumption

≤850w / ㎡

Operation humidity

10％～90％

Brightness adjustment

Adjust according to the environment

brightness software (0%-100%adjustable)

Gray scale

point by point 4096 gray grade levels of

each color, 16 bits γ correction available

Drive mode

Static, constant current

Frame frequency

≥60HZ

Input voltage

AC 110/220 volts

Operation temperature

﹣40℃~ +65℃

Average power consumption

≤400w / ㎡

Module dimension

160mm(W) * 160mm(H)

Control system

DVI card + master control card + receiver card

MTBF

>5000 hrs

Cabinet resolution

192 * 192pixel

Pixel pitch

5mm

Application:

Permanent installation available
