P3 Indoor HD Full Color 576mm x 576mm Cabinet Die-casting Aluminum LED Display
P3 Indoor HD Full Color 576mm x 576mm Cabinet Die-casting Aluminum LED Display
P3 Indoor HD Full Color 576mm x 576mm Cabinet Die-casting Aluminum LED Display
P3 Indoor HD Full Color 576mm x 576mm Cabinet Die-casting Aluminum LED Display
P3 Indoor HD Full Color 576mm x 576mm Cabinet Die-casting Aluminum LED Display
P3 Indoor HD Full Color 576mm x 576mm Cabinet Die-casting Aluminum LED Display
P3 Indoor HD Full Color 576mm x 576mm Cabinet Die-casting Aluminum LED Display
P3 Indoor HD Full Color 576mm x 576mm Cabinet Die-casting Aluminum LED Display
Specifications
Brand Name :
CNSRYLED
Model Number :
SRYLED-IFS-P3
Certification :
CE, LVD, RoHS
Place of Origin :
Shenzhen, China
MOQ :
4sqm
Price :
US$ 1,200 - 1,300 / Square Meter
Payment Terms :
T/T, Western Union, PayPal
Supply Ability :
1,000 Square Meter per Month
Delivery Time :
10 - 12 Working Days
Packaging Details :
Flight Case(8cabinet/case), size: 0.85x0.65x0.7m
LED Chip :
Epistar
Cabinet Material :
Die-casting Aluminum
Working Voltage :
110V - 220V ±15%, 50Hz
Warranty :
2 Full Years
Description

P3 Indoor HD Full Color 576mm x 576mm Cabinet Die-casting Aluminum LED Display

Quick Info.

Brand: CNSRYLED

Pixel Pitch: 3mm

LED Encapsulation: SMD2020

Color Configuration: 1R1G1B 3in1

Module Size: 192mm x 192mm

Cabinet Size: 576mm x 576mm

Cabinet Material: Die-casting Al

Warranty: 2 Full Years

Certifications: CE, LVD, RoHS

Place of Origin: Shenzhen, China

Specs.

Parameter P3
Module
 Pixel Configuration 1R1G1B SMD2020
Pixel Pitch 3mm
Module Resolution(W×H) 64dots x 64dots
Module Size 192mm x 192mm
Module Weight 0.24kg
Max Power Consumption 23W
Cabinet(Panel) Module Qty 9pcs
Cabinet Resolution(W×H) 192dots × 192dots
Cabinet Size 576mm x 576mm
Weight of One Cabinet 9kg
Cabinet Flatness ≤0.2mm
Cabinet Material Die-casting Cabinet
Optical Parameters Brightness Calibration by Per Dot Yes
White Balance Brightness ≥1,500nits
Color Temperature 3200K--9300K(adjustable)
View Angle Horizontal 160°, Vertical 160°
Brightness Uniformity ≥97%
Max.Contrast 4,000:1

Electrical Parameters

 Max Power Consumption(㎡) 680W/㎡
Average Power Consumption(㎡) 270W/㎡
Input Voltage AC 110V - 230V ± 15%
Processing Performance Driving Mode 1/32scan
Frame Rate(Hz) 120frame/sec
Refresh Frequency(Hz) ≥3,840HZ
Using Parameters Best Viewing Distance(m) 3 - 30m
Lifetime ≥100,000hrs
Working Temperature -20°C - + 60°C
Stored Temperature -30°C - + 70°C
Working Humidity(RH) 10% - 90%(no dew formation)
Stored Humidity(RH) 10% - 95%(no dew formation)
Waterproof NO
Statement: Product parameters table for reference only, the specific subject to the actual.

Competitive Advantages

1. HD play, delicate and clear.

2. Excllent encapsulte effect. Strong adaption to environment.

3. Higher cost performance, lower maintenance cost.

4. Small chip body combined with black mask, generating higher contrast ratio.

5. Strictly screening same LED wavelength, brightness voltage and etc to ensure the consistency of the whole screen.

6. High quality driving IC, combined with the control system which has more than 14bit processing, effecting a higher refresh rate.

7. High quality driving IC,combined with the control system which has more than 14bit processing, effecting a higher gray level.

8. Easy and fast to install and disassemble, without any tools.

Application

Business Organizations

Supermarket, large-scale shopping malls, exclusive agency, chain shops, largescale sales, starrated hotels, restaurants, travel agencies, pharmacy.

Financial Organizations

Banks, negotiable securities, funds, insurance companies, pawnshops;

Non-profit Organizations: Telecommunications, post offices, hospital,

schools;

Public Places

Subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers; Real Estate Property: Apartments, villas,offices, commercial buildings, model rooms, property brokers;

Entertainments

Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course
