Specifications
Brand Name :
ANNHUNG
Model Number :
AH-MS-B3
Certification :
CE, ISO9001, ICAO
Place of Origin :
China
MOQ :
1 Piece
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram, L/C
Supply Ability :
1000 pieces per month
Delivery Time :
2-20 days
Packaging Details :
Plastic bag with Paper Carton
Type :
Solar Aviation Obstruction Light Medium intensity Red 2000cd
Color :
Red
Light intensity :
≥2000cd
Flashing :
20FPM
Standard :
ICAO ANNEX 14 Medium intensity light, FAA L-864
Mode :
Built-in photo sensor for day/night operation
Description

Medium Intensity Solar Aviation Obstruction Light , Aviation Warning Lights Type B L864

This Medium-intensity Type B Aviation Obstruction Light flashing red color, designed for marking top of obstacle which height is between 45 to 105 meters.
GPS device is optional for AH-MS-B3 it make different lights flash synchronously no matter where those lights are.


Product Descripton

SPECIFICATIONS AH-MS-B3 Medium-intensity Type B L864 Solar Aviation Obstruction Light
Light Characteristics
Light Source Ultra high intensity CREE LED
Emitting Color Red
Intensity(cd) 2000cd±25%
Horizontal Output(degrees) 360
Vertical Divergence (degrees) ≥3
Flash Characteristics Flashing 20FPM,
Operation Mode Built-in photosensor
LED Life Experience(hours) >100,000
Electrical Characteristics
Operating Voltage(Vdc) 12
Circuit Protection Integrated
Solar Characteristics
Solar Module Type Mono crystalline Silicon
Output(watts) 6×4=24W
Charging Regulation Microprocessor controlled
Battery Characteristics
Battery type Valve-Regulated Lead Acid Battery(VRLA)
Nominal Voltage (V) 12
Battery Service Life Average 3 years
Autonomy (hours) 150
Physical Characteristics
Lamb Body Material UV protected Polycarbonate
Base Material Powder-coated Die-casting aluminum
Weight(kg) 9
Product Life Expectancy Average 3 years
Environmental Factors

Ambient Temperature(℃)

-55℃~+70℃

 -45~80
Humidity 0~100%
Wind Speed 80m/s
Waterproof IP67
Compliance
ICAO Annex 14 Volume 1,'Aerodrome Design and
Operations’ Sixth edition July 2013, table 6.3
Medium-intensity Type B Obstacle Light
FAA L-864
Optional

GPS Synchronization

GSM cellphone monitoring

NVG - compatible infrared (IR) LED

Medium Intensity Solar Aviation Obstruction Light , Aviation Warning Lights Type B L864

Medium Intensity Solar Aviation Obstruction Light , Aviation Warning Lights Type B L864


After-sales service
1. 2 years full warranty, 5 years maintenance since the purchasing date.
2. Since the purchasing date, full warranty from 1st year to 2nd year, free maintenance cost and material cost.
3. Since the purchasing date, maintenance from 3rd year to 5th year, free maintenance charge.

Packaging & Delivery time
Packaging: Paper carton 1-9 piece/box.
Delivery: In 2-10 days after payment.

Medium Intensity Solar Aviation Obstruction Light , Aviation Warning Lights Type B L864

AH-MS-B3 Medium Intensity Solar Aviation Obstruction Light , Aviation Warning Lights Type B L864 Datasheet download: download AH-MS-B3 LED Medium-intensity Type B L864...
