Specifications
Brand Name :
XUANCAI
Model Number :
4MM 5W/M Flexible Led Cob Strip Light
Certification :
CE ROHS LM-80
Place of Origin :
China
MOQ :
5 Meter/ Roll
Price :
$2-$6 / Metre
Payment Terms :
T/T, Western Union, Paypal , Alibaba trade assurance
Supply Ability :
100000M / Month
Delivery Time :
3-5 days
Packaging Details :
5M/Roll
Model :
4MM 5W/M Flexible Led Cob Strip
Wattas :
5W
Voltage :
DC24V
CRI :
>90
Luminous Efficacy :
110-120LM/W
CCT :
2700K 3000K 4000K 5000K 6000K 6500K
LED Qty(LEDs/M) :
480LEDs
Chip Brand :
Sanan chip
Storage Temperature :
-40...+85
Working Temperature :
-20...+45
Warranty :
2 Years Warranty
Spanlife :
50,000Hours
IP Rating :
IP20/ IP67
PCB Width :
4MM
Description

Flip Chip On Board DC24V 4MM 5W/M 480Leds Flexible COB Strip Tube Light White Red Blue Dotless FOB COB LED Strip

Product Description

Product Information
Product Model

4MM 5W/M Flexible Led Cob Strip light
FPC Width
4MM
Power
 5W/M, 25W/Roll
Voltage
DC24V

Color Temperature(CCT)

Warm White/ Natural White/ Cool White

LED Quantity(LEDs/ Meter)
480 Leds/ M, 512Leds/M
CRI(Ra)
90

Luminous Efficiency
110-120LM/W
Packaging Details 5Meter/Roll

Product Advantages as below:
1. Uniform illumination, dot free
2. 180 Beam Angle
3. better light decay
4. better heat-dissipation
5. High color efficiency
6. Waterproof: IP20-IP67
7. can be built-in aluminum profile with PC cover

Product Details

Product size
(mm)		 Input voltage
(V)		 Half a meter powe (W) Emitting color CRI Luminous efficiency
(LM/W)		 Color tolerance
500*04mm DC24V 2.5W 2700K ＞90 110-115 ≤3
500*04mm DC24V 2.5W 3000K ＞90 115-120 ≤3
500*04mm DC24V 2.5W 4000K ＞90 135-140 ≤3
500*04mm DC24V 2.5W 6500K ＞90 125-130 ≤3

FOB COB STRIP Dimension Image

Light White Red Blue Dotless Flip Chip On Board DC24V 6500k led strip

Reliability test standards

(Apilot project)

(Number of test)

(Test conditions)

(Decision criteria)

(Test Vequipment)
Cold and hot shock

10pcs

-40℃/30min -- 120℃/30min, one Cycle

per hour, 100 cycles in total.

No glue crack/dead light

Cold and heat shock

chamber
The normal temperature aging

10pcs

Ambient temperature 25±5℃, rated voltage /1000hr, 168H to test the photoelectric parameters once.

1Droop 10% or less

2.No glue crack/dead

light

 Normal temperature aging block
High temperature and high humidity

10pcs

 Ambient temperature 85±5℃, rated voltage /1000hr, 168H to test the photoelectric parameters once.

1.Droop 10% or less

2. No glue crack/dead light

High temperature and high humidity

aging tank

Packing method

1. Reel packaging

Light White Red Blue Dotless Flip Chip On Board DC24V 6500k led strip

LED light barwidth Reel size Meters per roll Number of rolls per carton
4mm 5.1 inches 5 10
8mm 5.1 inches 5 10
10mm 5.1 inches 5 10

2. Blister box packaging

Light White Red Blue Dotless Flip Chip On Board DC24V 6500k led strip

LED light barwidth

Blister box size

The packing layer

Number of packing strips per carton
4mm 510*123*25mm 10 300
8mm 510*123*25mm 10 150
10mm 510*123*25mm 10 120

Application

①Outdoor Lighting: Buildings, Advertising walls, Signs, Christmas decorations, Swimming pool, Park, Ice rinks

②Indoor Lighting: Polygonal wall, Ceiling groove design of hotel, Nightclub , KTV etc

③Home dark groove edge : Door frame, Bar, Wine cabinet, Wardrobe, TV cabinet...)

④Car beauty : Body,underside
