Specifications
Brand Name :
VW
Model Number :
P2.6,P2.97,P3.9,P4.8
Certification :
EMC,CE,FCC,ROHS
Place of Origin :
China
MOQ :
Negotiate
Price :
Negotiate
Payment Terms :
T/T
Supply Ability :
1000sqm per month
Delivery Time :
3-6 work days
Packaging Details :
Plywood case, export carton box
Pixel Pitch :
P2.6,P2.97,P3.9,P4.8
Material :
Die-casting Aluminum
Maintenance :
Front and Rear service
Cabinet Weight :
7.5kg
Cabinet Size :
500x500mm
Curved Angle :
-12° 3° 0° 12°
Brightness :
6000 nits
Contrast Ratio :
4500:1
Description

4500:1 High Contrast Ratio 500x500mm Cabinet Outdoor Indoor Stage Rental LED Display

Product Description:

High protection grade of IP65 suitable for winter and cold areas like North European countries and Russia, and high temperature like USA, Oman, UAE, etc


No deformation under sunlight by the use of Anti-UV module mask, Anti-Oxidation module frame with protection from deformation . Using high efficiency IC driver, improved PCB design, Power conversion efficiency.

Features:

  • Quick installation:Fast lock and cabinet magnet design for quick and easy installation.
  • Front & rear service:Can be front and rear maintenance, independent power box design.
  • Light weight:Only 7.5kg/cabinet, save shipping cost.
  • Hign contrast:4500:1 contrast ratio.​

Technical Parameters:

Technical Parameters Stage Rental LED Display
Product Model: P2.97 P3.9 P3.9 P4.8
Pixel Pitch: 2.97 mm 3.9 mm 3.9 mm 4.8 mm
LED Type: SMD2121 SMD2121 SMD1921 SMD1921
Cabinet Dimension: 500×500x77 mm 500×500x77 mm 500×500x77 mm 500×500x77 mm
Module Size: 250x250mm 250x250mm 250x250mm 250x250mm
Cabinet Weight: 7.5 kg 7.5 kg 7.5 kg 7.5 kg
Cabinet Material: Die-casting Aluminum Die-casting Aluminum Die-casting Aluminum Die-casting Aluminum
Driving Type: 1/21 1/16 1/16 1/9
Brightness: >1000 nits >1000 nits >5000 nits >5000 nits
Max/Avg Power: 560/224 W/sqm 560/224 W/sqm 780/312 W/sqm 780/312 W/sqm
Maintenance: Front & Rear service Front & Rear service Front & Rear service Front & Rear service
Environment: Indoor Use Indoor Use Outdoor Use Outdoor Use
IP Rating: F: IP30, R: IP30 F: IP30, R: IP30 F: IP65, R: IP54 F: IP65, R: IP54
Refresh Rate: >3840 Hz >3840 Hz >3840 Hz >3840 Hz
Installation Type: Hanging/Stacking Hanging/Stacking Hanging/Stacking Hanging/Stacking
Gray Scale: 14 bit 14 bit 14 bit 14 bit
Viewing Angle: H:140°;V:140° H:140°;V:140° H:140°;V:140° H:140°;V:140°
Operational Temp: -40℃~+60℃ -40℃~+60℃ -40℃~+60℃ -40℃~+60℃
Operational Humidity: 10%~90% RH 10%~90% RH 10%~90% RH 10%~90% RH

Applications:

Widely used in stage rental, song and dance activities, various conferences, exhibitions, stadiums, theaters, auditoriums, lecture halls, multi-function halls, conference rooms, performance halls, disco bars, nightclubs, high-end entertainment disco, TV Spring Festival Gala, important cultural activities in various provinces and cities and other places.

4500:1 High Contrast Ratio Stage Rental LED Display 500x500mm Cabinet Outdoor Indoor

4500:1 High Contrast Ratio Stage Rental LED Display 500x500mm Cabinet Outdoor Indoor

Picture:

Protect corner and anti-knock design, Can do convex and concave curved screen. (+12°, +3°, 0°, -12°)and 45° beveled cabinet for right angle screen, optional.

4500:1 High Contrast Ratio Stage Rental LED Display 500x500mm Cabinet Outdoor Indoor

Fast lock and cabinet magnet design for quick and easy installation

4500:1 High Contrast Ratio Stage Rental LED Display 500x500mm Cabinet Outdoor Indoor

FAQ:

Q1: Are you a factory or trading company?

A1: We are a factory.

Q2: Where is your factory located?How can I visit there?

A2: Our company is located in 2nd Floor, Building A, Tianyou Chuangke Hi-tech Industrial Park, No.2 Lixin Road, Bao'an District, Shenzhen 518103 China,are warmly welcome to visit us.

Q3: Does the P3.9 have CE/ROHS certificate?

A3: Yes,we can offer the CE/ROHS certificated for you as to your requirements.
