Specifications
Brand Name :
VW
Model Number :
P3.8 P6.67 P8 P10
Certification :
CE, ROHS
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
3000 sqm/month
Delivery Time :
15 days
Packaging Details :
Plywood case, Carton box
Product Name :
Outdoor LED Display Screen High Resolution Seamless Splicing Panel
Pixel Pitch :
3.81mm / 6.67mm / 8mm / 10mm
LED Type :
SMD
Cabinet DImension :
640mm * 640mm / 640mm *960mm
Module Size :
320mm * 320mm
Cabinet weight :
17KG /25KG
Max/Avg Power :
700/210 W/㎡
IP Rating :
IP68
Brightness :
5000 - 6000 nits
Description

Outdoor LED Display Screen High Resolution Seamless Splicing Panel

Product Description

Our Outdoor Flexible LED Display offers a 75° bending capacity, allowing it to adapt seamlessly to curved surfaces. With an IP68 waterproof rating and high refresh rate, it ensures vibrant, flicker-free visuals even in harsh weather, making it perfect for creative outdoor installations and impactful advertising.

Product Features

  • High Resolution: Available in pixel pitches ranging from 3.81mm to 10mm (P3.81, P6.67, P8, P10) to suit various display size and resolution requirements.
  • High Brightness: 5000-6000 nits brightness for excellent visibility in outdoor environments under direct sunlight.
  • IP68 Waterproof Rating: Protection against dust and water ingress for reliable operation in all weather conditions.
  • High Refresh Rate: Over 3840 Hz refresh rate for smooth, clear images without motion artifacts, ideal for dynamic content
  • Wide Operating Temperature Range: Operates reliably in temperatures ranging from -20°C to +60°C, suitable for various climates.

Technical Parameters

Product Model P3.81 P6.67 P8 P10
Pixel Pitch 3.81mm 6.67mm 8mm 10mm
LED Type SMD 1921 SMD3535 SMD3535 SMD3535
Cabinet Dimension 640*640/960 mm 640*640/960 mm 640*640/960 mm 640*640/960 mm
Module Size 320* 320 mm 320* 320 mm 320* 320 mm 320* 320 mm
Cabinet Weight 25/17 KG 25/17 KG 25/17 KG 25/17 KG
Cabinet Material Steel Steel Steel Steel
Driving Type 1/10 1/7 1/4 1/2
Brightness 5000 - 6000nits 5000 - 6000nits 5000 - 6000nits 5000 - 6000nits
Max/Avg Power 700/210 W/㎡ 700/210 W/㎡ 700/210 W/㎡ 700/210 W/㎡
Environment Outdoor Outdoor Outdoor Outdoor
IP Rating IP68 IP68 IP68 IP68
Refesh Rate >3840HZ >3840HZ >3840HZ >3840HZ
Installation Type Mounting/Hanging Mounting/Hanging Mounting/Hanging Mounting/Hanging
Gray Sacle 14Bit 14Bit 14Bit 14Bit
Viewing Angle H:120° V:120° H:120° V:120° H:120° V:120° H:120° V:120°
Operation Temp -20° ~ + 60° -20° ~ + 60° -20° ~ + 60° -20° ~ + 60°
Operation Humidity 10% ~ 90 % RH 10% ~ 90 % RH 10% ~ 90 % RH 10% ~ 90 % RH

Advantage

Flexible

Outdoor LED Display Screen High Resolution Seamless Splicing Panel Immersive Shows

High Performance

Outdoor LED Display Screen High Resolution Seamless Splicing Panel Immersive Shows

Outdoor LED Display Screen High Resolution Seamless Splicing Panel Immersive Shows

Outdoor LED Display Screen High Resolution Seamless Splicing Panel Immersive Shows

Outdoor LED Display Screen High Resolution Seamless Splicing Panel Immersive Shows

Q&A

FAQ:
Q1: What control system is used, and how does it work?

A1: We use the Nova Taurus Series asynchronous control system, which supports cluster playback and management. You can easily control it via various devices, including APP, smartphone, Wi-Fi, iPad, laptop, PC, or through cloud control. It's very user-friendly and convenient.

Q2: Can I place a sample order for an LED screen?
A2: Yes, we encourage sample orders for testing and quality evaluation. Mixed samples are also accepted.

Q3: Can I have my logo printed on the product?
A3: Absolutely. Please let us know in advance and confirm the design based on our sample before production begins.

Q4: What is your delivery time?
A4: Typically, delivery takes 7-15 days after the deposit is received. However, the exact time depends on the order size and items.

Q5: What is your warranty policy?
A5: We offer a 2-year warranty. We also provide full support for structure design, installation issues, system troubleshooting, and screen usage.
Our professional after-sales team, along with your dedicated sales engineer, will assist with any questions you may have after your order.
