Punch Light Power Supply 5V LED Display 350W LED Module Nature Hot Release Led Driver

Quick Detail:

• Indoor type aluminum shell
• AC/DC switching 5V 350W 70A single-switch LED driver
• AC input voltage: 90-130V or 170-250V
• 1600V High voltage test, over loading test and old aging test
• Constant voltage driver apply for LED module, LED display and punch light
• Size: 21.4*11.4*5.0cm
• Weight: 825g

Description:

For 5V Indoor types, we only have three models-200W, 300W and 350W, they are mainly used for LED display, punch light/lamp, LED module, light box etc.

Specifications:

Notices:

1. Input voltage should be within the specified voltage range (for examples: input voltage 220VAC).

2. Prohibited to be used in the high temperature environment, power port is the thermal vents, wind 50CM range, please do not place other objects, make sure that the power should have good thermal dissipation space environment.

3. Prohibited to install power supply in the presence of flammable materials (such as wood products, flammable plastic, etc), to stay away from petrol stations or where prohibited Fireworks.

4. Accurate calculation of load power, peak use, suggested user to use power supply based on power 80% load, do not overload.

5. Power supply have built-in short circuit protection function, when output short circuit, the power will automatically enter the status. Power off after 1 minute and then power on.

6. For safety, properly grounded, the output power cable must be ≥2.5mm²

7. Strictly in accordance with the position indicated by the output terminals of the power supply. It must be firm, check the output line and prohibited to be reversed (input "220VAC" main line, output "+" loaded for positive cathode, output "-" load for negative cathode).

8. Before power, check that the line voltage is compatible with the operating voltage with multimeter (voltage: 220VAC) recognized before it can be closed.

9. Power firm installed vertically (vertically in a place easy to wire the power supply, cover to cover, to be water proof)

5V Indoor types list:

S-300W-60A 5V 300W 60A Input voltage:90-130V or 170-250V 810g 21.4*11.4*5.0cm

S-350W-70A 5V 350W 70A Input voltage:90-130V or 170-250V 825g 21.4*11.4*5.0cm

Applications:

Widely used in LED Lighting, LED display, LED strips, LED advertisement screen, LED sign, LED night light, LED lamp house, LED decoration, LED wall light, LED street light , LED wall light, LED backlight, LED tube, offices , hospital , schools , factories , plants, shopping malls, supermarkets, kitchen, fair cabinet and so on.

FAQ

1. How many models you produce for indoor 5V series?

A: There are three models----5V 200W 40A, 5V 300W 60A and 5V 350W 70A etc. sometimes, we also produce 5V 400W 80A type if good quantity.

2. Do you have CE, ETL approval?

A: we don’t have such approvals for 5V series, but we can supply CE and ETL approvals if you require.

3. Can I place a sample order?

A: Yes, sample order is available

4. What about lead time?

A: 3-5 days for sample, 8-15 working days for mass production orders

5. Which tests do you carry out in your factory?

A: We do over load test, 1600V high voltage test and 100% old age test.

6. What is MOQ for led driver?

A: MOQ usually is 500pcs except sample order.
