ATEX LED Explosion Proof Flood Light
ATEX LED Explosion Proof Flood Light
ATEX LED Explosion Proof Flood Light
ATEX LED Explosion Proof Flood Light
ATEX LED Explosion Proof Flood Light
ATEX LED Explosion Proof Flood Light
ATEX LED Explosion Proof Flood Light
ATEX LED Explosion Proof Flood Light
ATEX LED Explosion Proof Flood Light
ATEX LED Explosion Proof Flood Light
Specifications
Brand Name :
KHJ
Model Number :
Ex-KT80,Ex-KT100,Ex-KT120
Certification :
ATEX,IECEx,CE,RoHS
Place of Origin :
Guangdong, China
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
400pcs per day
Delivery Time :
3-8 work days
Packaging Details :
1234*281*165mm
Product Name :
Swordfish series
Operating Voltage :
100-277 VAC/24-48 VAC;10-30 VDC/24-48 VDC/141-392 VDC
Rated Power :
36W 48W 56W 72W
Luminarie Efficacy :
136.5lm/W
Area Classification :
Group II Zone 1 & 21 and 2 & 22
Power Factor :
＞0.98
THD :
＜10%
Surge Protection :
6KV
Description

ATEX certified LED Explosion Proof Flood Light Ex Swordfish series with emergency function

LED Explosion proof light 36W 48W 56W 72W LED Strip Lighting

Highlight: LED Explosion Proof Flood Light, Ex linear

Features And Benefits:

1. It is available in 0.6m and 0.9m lengths, installation options and emergency options.
2. The slim, streamlined design of linear lights in hazardous areas allows access to limited space at a low installation height.

3. Designed to replace traditional linear fluorescent lighting fixtures.

4. The independent LED and the driver chamber with external airflow heat sink provide excellent heat dissipation to ensure long life.
5. It has over-voltage, over-current, and surge current protection.
6. IP66 waterproof and dustproof, with a life of more than50000hrs.

Product Important Information:

Type Of Protection Ex d eb ,Ex tb
Protection Standards

(IEC)EN 60079-0, (IEC)EN 60079-1, (IEC)EN 60079-7, (IEC)EN 60079-28, (IEC)EN 60079-31

EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3,

EN 60598-1, EN 60598-2-5, EN 62031, EN 62493,

IEC 62321-4, IEC 62321-5, IEC 62321-6, IEC 62321-7-1, IEC 62321-7-2, IEC 62321-8
Area Classfiction Zone 1 and Zone 2 Areas to (IEC)EN 60079-10-1,Zone 21 and Zone 22 Areas to (IEC)EN 60079-10-2
Installation (IEC)EN 60079-14
Certificate IECEx_TUR_16.0028X/TÜV 15 ATEX 7673 X
Equipment Coding

□Ex d eb op is IIB T6 Gb ,Ex tb op is IIIC T80℃ Db

□Ex d eb op is IIC T6 Gb , Ex tb op is IIIC T80℃ Db
Temperature Class Rated power (W) -20℃ ≤ Ta ≤ +55℃
Gas Dust
36W~72W T6 T80℃
ATEx Coding ATEX LED Explosion Proof Flood LightII 2 G / II 2 D
Ingress Protection IP66 (IEC)EN 60529
Cable entry M20*1.5,M25*1.5,3/4 NPT
CE Mark

The CE marking of this product applies to EU directives 2014/35/EU, 2014/30/EU, 2012/19/EU , 2011/65/EU and 2014/34/EU respectively.

The Equipment is declared to meet the provisions of the ATEX directive(2014/34/EU)by reason of the EC

Type Examination and compliance with the Essential Health and Safety Requirements

Applications:

Ex SwordFish series is applicable for zone I and zone II , or gas area, restricted area or heavy industrial processing equipment area, drilling platform and other coastal or offshore dangerous areas, Such as port, ship, oil, petrochemical, oil depot.

ATEX LED Explosion Proof Flood Light

Ordering information:

P/N

Operating Voltage(V)

Luminous Flux(lm)

Power

(W)

CRI

Color Temp.

CCT(K)

Temp. Classification
Ex-KSF361200H7V7WM-E

100-277 AC

(141-392 DC)

 4536 36 82 Warm white 3000±300

T6
Ex-KSF361200H7V7NH-E 4914 36 70 Natural white 4000±300
Ex-KSF361200H7V7NH-E 4914 36 70 Natural white 5000±300
Ex-KSF361200H7V7CH-E 4914 36 70 Cool white 5700±300
Ex-KSF481200H7V7WM-E 6048 48 82 Warm white 3000±300
Ex-KSF481200H7V7NH-E 6552 48 70 Natural white 4000±300
Ex-KSF481200H7V7NH-E 6552 48 70 Natural white 5000±300
Ex-KSF481200H7V7CH-E 6552 48 70 Cool white 5700±300
Ex-KSF561200H7V7WM-E 7056 56 82 Warm white 3000±300
Ex-KSF561200H7V7NH-E 7644 56 70 Natural white 4000±300
Ex-KSF561200H7V7NH-E 7644 56 70 Natural white 5000±300
Ex-KSF561200H7V7CH-E 7644 56 70 Cool white 5700±300
Ex-KSF721200H7V7WM-E 9072 72 82 Warm white 3000±300
Ex-KSF721200H7V7NH-E 9828 72 70 Natural white 4000±300
Ex-KSF721200H7V7NH-E 9828 72 70 Natural white 5000±300
Ex-KSF721200H7V7CH-E 9828 72 70 Cool white 5700±300
