Robust Construction Explosion Proof LED High Bay Lighting 320W 400W 480W
Robust Construction Explosion Proof LED High Bay Lighting 320W 400W 480W
Robust Construction Explosion Proof LED High Bay Lighting 320W 400W 480W
Robust Construction Explosion Proof LED High Bay Lighting 320W 400W 480W
Robust Construction Explosion Proof LED High Bay Lighting 320W 400W 480W
Robust Construction Explosion Proof LED High Bay Lighting 320W 400W 480W
Robust Construction Explosion Proof LED High Bay Lighting 320W 400W 480W
Robust Construction Explosion Proof LED High Bay Lighting 320W 400W 480W
Robust Construction Explosion Proof LED High Bay Lighting 320W 400W 480W
Robust Construction Explosion Proof LED High Bay Lighting 320W 400W 480W
Robust Construction Explosion Proof LED High Bay Lighting 320W 400W 480W
Robust Construction Explosion Proof LED High Bay Lighting 320W 400W 480W
Robust Construction Explosion Proof LED High Bay Lighting 320W 400W 480W
Robust Construction Explosion Proof LED High Bay Lighting 320W 400W 480W
Specifications
Brand Name :
KHJ
Model Number :
Ex-KT320,Ex-KT400,Ex-KT480
Certification :
ATEX,IECEx,CE,RoHS
Place of Origin :
Guangdong, China
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
400pcs per day
Delivery Time :
3-8 work days
Packaging Details :
671*426*142mm
Product Name :
Tank Series
Operating Voltage :
100-277 VAC, 347-480 VAC,141-391VDC,491-679 VDC
Power :
320W 400W 480W
Luminaire Efficacy :
Max:152lm/W
Area Classification :
Group II, Zone 1 & 21 and 2 & 22
Lifespan :
>50,000 hours
Frequency :
50/60Hz
Power Factor :
＞0.98
Description

Robust construction Explosion Proof LED High Bay Lighting Ex Tank Series 320W 400W 480W

Ex Tank Series 320W,400W and 480W Explosion Proof LED High Bay Lighting

Highlight: Explosion Proof LED High Bay Lighting,Ex Tank Series high power LED lighting

Features And Benefits:
1. Copper-free aluminum housing.
2. Temperature compensation technology for longer life.
3. High efficacy: up to 140lm/W.
4. Tempered and impact-resistant glass globe, heat- and corrosion-proof.

5. 320W,400W and 480W available. Optional luminous intensity distribution for different applications.

6. All external hardware are stainless steel.


Product Important Information:

Type Of Protection Ex db ,Ex tb
Protection Standards

(IEC)EN 60079-0, (IEC)EN 60079-1, (IEC)EN 60079-28, (IEC)EN 60079-31
EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3,
EN 60598-1, EN 60598-2-5, EN 62031, EN 62493,
IEC 62321-4, IEC 62321-5, IEC 62321-6, IEC 62321-7-1, IEC 62321-7-2, IEC 62321-8
Area Classfiction

Zone 1 and Zone 2 Areas to (IEC)EN 60079-10-1,
Zone 21 and Zone 22 Areas to (IEC)EN 60079-10-2
Installation (IEC)EN 60079-14
Certificate pending
Equipment Coding

II 2 G Ex db IIC T* Gb
II 2 D Ex tb IIIC T* Db IP66
Temperature Class Rated power (W) -40℃ ≤ Ta ≤ +55℃
Gas Dust
320W~480W T5 T95℃
ATEx Coding Robust Construction Explosion Proof LED High Bay Lighting 320W 400W 480WII 2 G / II 2 D
Ingress Protection IP66 (IEC)EN 60529
Cable entry M20*1.5,M25*1.5,3/4 NPT
CE Mark

The CE marking of this product applies to EU directives 2014/35/EU, 2014/30/EU, 2012/19/EU , 2011/65/EU and 2014/34/EU respectively.
The Equipment is declared to meet the provisions of the ATEX directive(2014/34/EU)by reason of the EC
Type Examination and compliance with the Essential Health and Safety Requirements

Applications:
It is the ideal solution for the illumination of on- and offshore plants in the oil and gas industry, chemical plants, waste disposal facilities, shipyards, power stations and mills where extreme amounts of dirt and moisture and increased mechanical hazard are to be expected.
Robust Construction Explosion Proof LED High Bay Lighting 320W 400W 480W

Ordering information:

P/N

Operating Voltage(V)

Luminous Flux(lm)

Power(W)

CRI

Color Temp.

CCT(K)

Temp. Classification
Ex-KTK320**CH-S4-E

100-277 VAC(141-392 VDC)

 46400

320

 70 Cool white 5700±300k T5
Ex-KTK320**NH-S4-E 46400 70 Natural white 5000±300k T5
Ex-KTK320**NH-S4-E 46400 70 Natural white 4000±300k T5
Ex-KTK320 **WM-S4-E 41760 70 Warm white 3000±300k T5
Ex-KTK400**CH-S4-E 58054

400

 70 Cool white 5700±300k T5
Ex-KTK400**NH-S4-E 58054 70 Natural white 5000±300k T5
Ex-KTK400**NH-S4-E 58054 70 Natural white 4000±300k T5
Ex-KTK400 **WM-S4-E 52248 70 Warm white 3000±300k T5
Ex-KTK480** CH-S4-E 69120

480

 70 Cool white 5700±300k T5
Ex-KTK480** NH-S4-E 69120 70 Natural white 5000±300k T5
Ex-KTK480** NH-S4-E 69120 70 Natural white 4000±300k T5
Ex-KTK480** WM-S4-E 62208 70 Warm white 3000±300k T5

Remarks:

1. The first * stands for Operating Voltage including default -100-277VAC,D-347-480VAC.

2. The second * stands for Candela Distribution including H3V3,H5V5,H6V6.

Competitive advantages of our factory:

1. Very competitive price and high quality control.

2. Timely delivery.

3. Environmentally friendly products.

Why choose us?

1.Professional lighting manufacturer for more than 10 years.
2. Gold supplier.
3. Provide high quality products and best service.
