Specifications
Brand Name :
KHJ
Model Number :
Ex-KSL30,Ex-KSL45,Ex-KSL60,Ex-KSL80
Certification :
ATEX,IECEx,CE,RoHS
Place of Origin :
Guangdong, China
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
400pcs per day
Delivery Time :
3-8 work days
Packaging Details :
405*405*200mm
Product Name :
Sealion Series
Operating Voltage :
100~277 VAC, 141~392 VDC, 347~480VAC (60-80W), 491~679VDC (60-80W)
Power :
30W,45W,60W,80W
Luminaire Efficacy :
140lm/W
Area Classification :
Group II, Zone 1 & 21 and 2 & 22
Cable Entries :
2XNPT 3/4” (M20*1.5, M25*1.5 are optional)
Earthing Protection :
M4 (Internal & external earth bolts)
IP Code :
IP66
Description

Explosion Proof Lighting Zone 1 30W 45W 60W 80W high quality Sealion Series

Hazardous Area & Explosion Proof LED lighting

Zone 1

30W 45W 60W 80W

Sealion Series led light

Highlight: LED Explosion Proof Lighting Zone 1, explosion proof LED lights.

Features And Benefits:

1. Energy saving. Reduce the number of luminaires needed, providing excellent luminaries efficacy more light where you need it.

2. High efficacy LED Source with long lifespan>50,000 hours.

3. Corrosion resistant epoxy coated die casting aluminum alloy body and high impact resistance tempered glass diffuser.

4. ATEX /IECEx certified for Zone 1, 2, 21 and 22.

5. Optional luminous intensity distribution for different applications.

6. Wire guard available.

7. Ambient temperature from -40℃to 55℃.


Product Important Information:

Type Of Protection Ex d,Ex tb
Protection Standards

(IEC)EN 60079-0, (IEC)EN 60079-1, (IEC)EN 60079-7, (IEC)EN 60079-18, (IEC)EN 60079-31

EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3,

EN 60598-1, EN 60598-2-5, EN 62031, EN 62493,

IEC 62321-4, IEC 62321-5, IEC 62321-6, IEC 62321-7-1, IEC 62321-7-2, IEC 62321-8
Area Classfiction Zone 1 and Zone 2 Areas to (IEC)EN 60079-10-1,Zone 21 and Zone 22 Areas to (IEC)EN 60079-10-2
Installation (IEC)EN 60079-14
Certificate

TÜV 20 ATEX 8608 X

IECEx TUR 20.0068X
Equipment Coding

II 2 G Ex db IIC T4/T5 Gb

II 2 D Ex tb IIIC T115°C/105°C/T95°C Db IP66
Temperature Class Rated power (W)

-20℃≤Ta≤+55℃

with Battery

 -40℃≤Ta≤+55℃ -40℃≤Ta≤ +65℃
Gas Dust Gas Dust Gas Dust
30W T5 T95˚C T5 T95˚C T4 T105˚C
45W T5 T95˚C T5 T95˚C T4 T105˚C
60W T5 T95˚C T5 T95˚C T4 T105˚C
80W T5 T95˚C T5 T95˚C / /
ATEx Coding Oil Industrial Zone 1 Explosion Proof Lighting 30W 45W Energy SavingII 2 G / II 2 D
Ingress Protection IP66 (IEC)EN 60529
Cable entry M20*1.5,M25*1.5,3/4 NPT
CE Mark

The CE marking of this product applies to EU directives 2014/35/EU, 2014/30/EU, 2012/19/EU , 2011/65/EU and 2014/34/EU respectively.

The Equipment is declared to meet the provisions of the ATEX directive(2014/34/EU)by reason of the EC

Type Examination and compliance with the Essential Health and Safety Requirements

Applications:

Explosion Proof Lighting Zone 1 suitable for onshore and offshore oil, gas, petrochemicals and process industries etc.

Oil Industrial Zone 1 Explosion Proof Lighting 30W 45W Energy Saving

Ordering information:

P/N

Operating

Voltage(V)

Luminous Flux(lm)

Power

(W)

CRI

Color Temp.

CCT(K)

 Temp. Classification
-40℃-+55℃ -40℃-+65℃
Ex-KSL30*WM-E

100~277

AC

(141~

392DC)

 3900 30 70 Warm white 3000±300 T5 T4
Ex-KSL30*NH-E 4410 30 70 Natural white 4000±300 T5 T4
Ex-KSL30*NH-E 4410 30 70 Natural white 5000±300 T5 T4
Ex-KSL30*CH-E 4410 30 70 Cool white 5700±300 T5 T4
Ex-KSL45*WM-E 5850 45 70 Warm white 3000±300 T5 T4
Ex-KSL45*NH-E 6615 45 70 Natural white 4000±300 T5 T4
Ex-KSL45*NH-E 6615 45 70 Natural white 5000±300 T5 T4
Ex-KSL45*CH-E 6615 45 70 Cool white 5700±300 T5 T4
Ex-KSL60*WM-E 7800 60 70 Warm white 3000±300 T5 T4
Ex-KSL60*NH-E 8820 60 70 Natural white 4000±300 T5 T4
Ex-KSL60*NH-E 8820 60 70 Natural white 5000±300 T5 T4
Ex-KSL60*CH-E 8820 60 70 Cool white 5700±300 T5 T4
Ex-KSL80*WM-E 10400 80 70 Warm white 3000±300 T5 T4
Ex-KSL80*NH-E 11760 80 70 Natural white 4000±300 T5 T4
Ex-KSL80*NH-E 11760 80 70 Natural white 5000±300 T5 T4
Ex-KSL80*CH-E 11760 80 70 Cool white 5700±300 T5 T4

Remarks:

1. *Stands for beam angle , including H4V4 / H5V5 / H6V6.

2. For beam angle H4V4 and H5V5,the luminous flux will be 15% less.

Competitive advantages of our factory:

1. Very competitive price and high quality control.

2. Timely delivery.

3. Environmentally friendly products.

4. Various designs.

5. Accept small orders.
