Specifications
Brand Name :
ZLONE
Model Number :
ZL-FL410-100W
Certification :
CE ROHS TUV SGS FCC IP65
Place of Origin :
China
MOQ :
1pc
Price :
negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
50,000pcs/Month
Delivery Time :
7-10working days
Packaging Details :
Packing Size: 430*370*620mm 4pcs/Carton N.W:3.46kg/pcs G.W:3.77kg/pcs
Power :
100W
Input Voltage :
90-260vac 50/60Hz
Lampe efficiency :
90-100lm/W
Material :
Aluminium Cover with Toughened Glass
Certificate :
CE ROHS UL TUV SGS
CCT :
WW:3000K, NW:4000K,CW:6000K
IP Rating :
IP65
Driver :
Meanwell Driver
Description

11000LM High Wattage Cree Outdoor Led Flood Lights Football Ground Led Floodlight

SPEC of ZLONE led flood light:


1. Single color & RGB led bulb. Can get fantastic color changing effects.
2. Easy plug technology,more reliable and easy maintenance.
3. IP65/IP68 protection.Waterproof and dustproof.
4. Energy saving, saving 50% than the traditional lights at the same brightness.
5. Inner high efficiency (95%) heat protection system, with the latest high efficiency constant,currency driver, making the products can work under unstable voltage.
6. Long life span, more than 50000 hours.

Optical Parameters of High power LED Floodlight 100w

Model

ZL-FL410-100W

Power

100W

LED chip

Epistar /Bridgelux 45mil LED chip

Lumens

9900 lm

Color Temperature

2700-6500k

Warm White: 2700-3200k

Neutral White/Nature white 4000-4500K

Day White: 5000-5500K

Cool White, Cold White > 6500K

CRI

>75

Beam Angle

120 degre

Physical parameters of LED floodlight 100W

Housing Material

Aluminum Alloy + Toughened glass

Surface Treatment

Oxidation Treatment, Silver Treatment

Current

950 mA

Voltage

AC 85-265V

Frequency

50/60 HZ

LED driver

Meanwell Driver

Power Factor

0.90

Power Efficiency

85%

RGB flood light is available

Customized your LED flood light:

1. Different led chip brand:Epistar/Bridgelux/CREE

2. Dimmable are available,compatible most dimmer,RF remote prepared

3. Isolated power supplier and non-isolated power could be chosen.

4. Regular lumen 90-100lm/w,Highest lumen 130lm/w or 120-140lm/w for chosen.

5. Different power supplier solution:lowest temperature upto -40 degree.it could be updated to Meanwell power supplier.

6. Long life span,20000/50000 hours,2-5 years warranty by your request.

-------------------------------------PRODUCT Feature ---------------------------------------

1. Led chip: High lumen EPISTAR chip-on-board chips or BRIDGELUX delivery 130lm/w high lumens in high CRI for lighting performance and have 120o beam angle for lighting.

2. Lifespan: ZLONE’s led flood light has 50000 hours lifespan for using. You can using 8 years base on using 10 hours per day.

3. Led Power Supply: Constant current Mean well series power supply will protect LED chip in correct current and voltage. It provide power factor >0.9 and power efficient > 90% characteristic to ensure power saving. Also it has over current, over voltage, over temperature and short circuit protection to ensure the long time lifespan.

4. Lamp Housing: High quality aluminum alloy housing with spray painting surface finish, dust-resistant, moisture-proof, firm and durable. The lead time of manufacture is fast because of die-casting production process. Also the quality of the lamp housing is same.

5. Glass Cover: High quality 4mm-5mm thickness heat-resistant temper glass will not splash when the flood light is exploded in wrong operation. It guarantees 100% light transmittance and uniform light distribution.

6. Heat sink: Sufficient and thickness liner radiation fin are average distributed on the back of front head by die-casting technology with excellent thermal conductivity.

7. IP65 waterproof structure:Every gap, screw and interface used the rubber ring with silica gel for waterproof purpose.

8. Adjustable bracket: It can adjust 0-180o beam angle in horizontal direction for different application purpose.

9. Warranty: ZLONE offers 3 years product warranty for all products. If you need 5-years warranty for this wattage product, please contact us directly.

Related products of LED Flood Light:

Size(mm)

Power

Lumen

Efficiency

CRI

Beam

Voltage

IP Grade

N.W

Replacement

115*85*85

10W

800lm

80 lm/w

>75

120°

85~265V

IP65

700g

30W HPS

180*140*110

20W

1600lm

80 lm/w

>75

120°

85~265V

IP65

1500g

60W HPS

225*185*125

30W

2400lm

80 lm/w

>75

120°

85~265V

IP65

2580g

100W HPS

288*238*160

50W

4000lm

80 lm/w

>75

120°

85~265V

IP65

4000g

150W HPS

360*285*130

70W

5600lm

80 lm/w

>75

120°

85~265V

IP65

7000g

200W HPS

360*285*97

80W

6400lm

80 lm/w

>75

120°

85~265V

IP65

7000g

250W HPS

425*328*190

100W

8000lm

80 lm/w

>75

120°

85~265V

IP65

7500g

300W HPS

425*328*190

120W

9600lm

80 lm/w

>75

120°

85~265V

IP65

8600g

350W HPS

425*328*190

150W

12000lm

80 lm/w

>75

120°

85~265V

IP65

9000g

500W HPS

Applications:

Ideal lamp for Warehouse, Basketball Court, Sports Center, Gymnasium halls, Football Field,Tennis Field and etc.
