Concert Stage Aluminum Square Bolt Truss SQB300 Concert Stage Trussing System
Concert Stage Aluminum Square Bolt Truss SQB300 Concert Stage Trussing System
Concert Stage Aluminum Square Bolt Truss SQB300 Concert Stage Trussing System
Concert Stage Aluminum Square Bolt Truss SQB300 Concert Stage Trussing System
Concert Stage Aluminum Square Bolt Truss SQB300 Concert Stage Trussing System
Concert Stage Aluminum Square Bolt Truss SQB300 Concert Stage Trussing System
Specifications
Brand Name :
LEDIKA
Model Number :
SQB300
Certification :
ISO9001
Place of Origin :
Guangzhou, China
MOQ :
10pcs
Price :
negotiable
Payment Terms :
T/T, L/C
Supply Ability :
10000pcs per month
Delivery Time :
15 days
Packaging Details :
Carton or bubble bag
Connector :
bolt/ screw
Package :
carton box
Material :
6082 T6 Aluminum
Logo :
LEDIKA
Junction :
aluminum plated
Truss section :
300 x 300 mm
Code :
SQB300
Length :
0.5m-4m
Color :
Silver, black, red
Application :
booth, exhibition, concert, stage
Shape :
Square
Tube size :
50*3mm
Weight :
3kg per meter
Span :
12m
Description

Aluminum Square Bolt Truss SQB300 for Concert Stage Trussing

Description

Aluminum Spigot Light Truss System mainly use in performance.
It have enough loding capability for used in heavy project.
Aluminum Spigot Light Truss System use range: Event, outdoor show, fashion show, concert, rental party, wedding, booth.

Bolt truss sizes:
100X100mm / 150X150mm / 200X200mm / 250X250mm / 300X300mm / 350X350mm / 400X400mm/ 450X450mm / 400X600mm / 500X500mm / 500X600mm / 520X760mm / 600X760mm
Main tube: 50*2mm/50*3mm, 50*4mm, brace: 20*2mm, 25*2mm, 30*2mm

Aluminum Box Truss

  • Material : Aluminum 6082-T6
  • Size : As customized
  • Color: Black,Silver,Red,etc.
  • Connection : Bolt
  • Constitute : Beam + Pillar + Sleeve + Base + Controller + Hoist + Flight Belt

View

Concert Stage Aluminum Square Bolt Truss SQB300 Concert Stage Trussing System

Concert Stage Aluminum Square Bolt Truss SQB300 Concert Stage Trussing System

Concert Stage Aluminum Square Bolt Truss SQB300 Concert Stage Trussing System

Allowable Loading

SQB 300 Allowable Loading
6082-T6 50*3mm tube as main tube 25*2mm as brace tube
Span LOAD ALL Unitformly distributed load(UDL) Centre point load(CPL) DEFLECTION
m ( ft ) kg kg/m kg (mm)
4 13.1 1155 289 462 5
5 16.4 924 185 462 11
6 19.7 924 154 462 17
7 23 924 132 462 31
8 26.2 901 113 451 52
9 29.5 800 89 400 68
10 32.8 722 72 361 87
11 36 658 60 329 108
12 39.3 602 50 301 130

Company profile

Through 15 years development,LEDIKA is becoming an integrative company on aluminum truss, layer

truss, LED lighting, stage and flight case,professionally in studying, designing, producing, renting and

mounting together.

"LEDIKA"approached its brand and own its wide market. We participated in the builder of 2007 Special Olympics Games Opening Ceremony,2008 Beijing Olympics Games, 2010 the 16th Asian Games.

Honesty, humanist and innovation are our base to develop.

About Us

Concert Stage Aluminum Square Bolt Truss SQB300 Concert Stage Trussing System

LEDIKA Flight Case & Stage Truss Co., Ltd. was established in the year of 2001, located in Guangzhou city of China.

Through 15 years development, we are becoming an integrative company on aluminum truss, layer truss, ,stage and flightase ,professionally in studying,designing,producing,renting and mounting together.

“LEDIKA”approached its brand and own its worldwide market .Specially in 2007 Shanghai Summer Special Olympics, and 2010 Asian games ,and its folding truss are used in international and gain more trust and support from all over the word.


Type of Trading

Payment Terms T/T, L/C, Western Union
Payment 50% TT in davance, the balance should be against before shipment
Delivery 15-20 working days after receive your deposit
Loading Port Guangzhou / Shenzhen



FAQ
1. Q: Are you a dealer?
A: No. We have our own factory that covers an area of 3,000 square meters.
2. Q: Can you make customized products?
A: Absolutely. You just need to send us your requirement about the item or design.
3. Q: What does your factory do regarding quality control?
A: Quality is our priority, we pay great attention to the quality from the beginning to the end.
And we never sell low quality products for lower price.
