30M Max Span Aluminum Box Truss 3mm Thickness 0.5M - 4M Length For Outdoor Event
30M Max Span Aluminum Box Truss 3mm Thickness 0.5M - 4M Length For Outdoor Event
Specifications
Brand Name :
LEDIKA
Model Number :
SQS/SQB
Certification :
ISO9001
Place of Origin :
Guangzhou, China
MOQ :
1set
Price :
negotiable
Payment Terms :
T/T 30% deposit, 70% balance
Supply Ability :
50set per month
Delivery Time :
15 days after received your deposit
Packaging Details :
Carton with film
Product Name :
Aluminum Box Truss
Series :
Heavy Series
Size of truss system :
Customized
Material :
Aluminum 6082-T6
Application :
Exhibition,Concert
Payment terms :
L/C, T/T, Paypal
Connection :
Bolt or spigot
Description

30M Max Span Aluminum Box Truss 3mm Thickness 0.5M - 4M Length For Outdoor Event

Product Description

1)Aluminum Box Truss uses international standard 6082-T6 material, with the advantages of beautiful appearance,small volume, easy to set up and transport, itself also has the advantages of excellent compressive and anticorrosive performance; the truss average loading can meet many kinds of performances, business conferences audio equipment requirements. Other irregular shapes can be customized according to the customers' requirements.

2)This heavy duty truss is for those projects with ever increasing load and distance requirements. The truss is plated and connected with included 8.8 degree M16*45mm bolts as standard and can be combined with Towers and suitable sleeve blocks to create a roof system perimeter or LED screen support structure. This truss can be supplied with casters. The Main Tube is Diameter 50mm, Thickness is 3mm Aluminum tube. And it also Strenghten quadrate to make sure the truss can hold the heavy duty.


Truss of Heavy Series

Size of Truss450x600mm520x760mm600x760mm520x1000mm
ConnectionSpigot/BoltSpigot/BoltSpigot/BoltSpigot
Truss main tubeDiameter Ø 50mm , Thickness 3mmDiameter Ø 50mm , Thickness 3mmDiameter Ø 50mm , Thickness 3mmDiameter Ø 50mm , Thickness 3mm
Truss sub-tubeDiameter Ø 50mm , Thickness 2mmDiameter Ø 50mm , Thickness 2mmDiameter Ø 50mm , Thickness 2mmDiameter Ø 50mm , Thickness 2mm
Truss brace tubeDiameter Ø 30mm , Thickness 2mmDiameter Ø 30mm , Thickness 2mmDiameter Ø 30mm , Thickness 2mmDiameter Ø 30mm , Thickness 2mm
Truss Joint50x40mmØ50/60mm,50x40mmØ50/60mm,50x40mm50x40mm
Max Loading630-3400kg840-4100kg840-4100kg780-4700kg
Max Span22m24m24m30m



Advantage

1. The heavy duty truss is made of aluminum with high hardness. material: 6082-T6.
2.Beautiful appearance and durable.
3.Assemble the accurate positioning, simple.
4.It is suitable for all kind of indoor and outdoor performances.
5.We can manufacture the dimension as your requirement.
6.Reasonable price.
7.OEM/ODM is welcome.



Other Information of Product

Warranty: 2 Years
Sample: Depends on the quantity of order.
Design: Any designs can be customized.


Project photos for reference:
