Stage Truss Systems Aluminum Square Truss For Outdoor Parties Length 0.5 - 4m
Stage Truss Systems Aluminum Square Truss For Outdoor Parties Length 0.5 - 4m
Stage Truss Systems Aluminum Square Truss For Outdoor Parties Length 0.5 - 4m
Stage Truss Systems Aluminum Square Truss For Outdoor Parties Length 0.5 - 4m
Stage Truss Systems Aluminum Square Truss For Outdoor Parties Length 0.5 - 4m
Stage Truss Systems Aluminum Square Truss For Outdoor Parties Length 0.5 - 4m
Stage Truss Systems Aluminum Square Truss For Outdoor Parties Length 0.5 - 4m
Stage Truss Systems Aluminum Square Truss For Outdoor Parties Length 0.5 - 4m
Specifications
Brand Name :
LEDIKA
Model Number :
SQB400
Certification :
TUV/ISO9001
Place of Origin :
Guangzhou, China
MOQ :
10pcs
Price :
$60-$200 per meter
Payment Terms :
T/T, L/C
Supply Ability :
10000pcs per month
Delivery Time :
within 2-3 weeks
Packaging Details :
Carton or bubble bag
Material :
6082 T6 Aluminum
Truss size :
400 x 400mm
Length :
0.5m-4m
Color :
Silver, black, red
LOGO :
LEDIKA
Shape :
Square
Tube size :
50*3mm
Weight :
10kg per meter
Application :
Games, events, LED screen
Description

Concert Truss System Aluminum Square Truss For Outdoor Parties Length 0.5 - 4m

Description

All of our truss can be retread and reused, because it has high corrosion resistance, non-toxic with high
technical welder and good quality of alloy Al-aluminum tube, resonable price can help you save the
expenditure, the main characteristic is using of easy, quick buliding, stronger loading capacity, which is mainly used for movable performence stage, ceremonies, the indoor exhibition, planes, the studio, hanging lights, product fairs, exhibition halls display, and other structures need to meet a variety of projects.

Specifications

Truss Material Aluminum 6082 T6degrees hardness
Light Series 287x287mm,290x290mm,300x300mm
Medium Series 450x450mm,400x400mm,387x387mm
Heavy Series 520x1000mm,520x760mm,600x760mm,450x600mm
Truss main tube Ø 50mm , Thickness 3mm
Truss sub-tube Ø 50mm , Thickness 2mm
Truss brace tube 20*2mm,25*2mm,30*2mm,30*3mm
Length available 0.5m-4m(Normal length ) or customized
Max Span 12-30m
Max loading 500-4700kg

Advantages

1. 16 years perfessional stage truss big events experience since 2001.


2. Projects case covers all over the world.


3. As the government tender brand, LEDIKA is famous in many countries


4. OEM and R&D is acceptable.


5. We participate in prolight show each year.


6. Owning material 6082 T6 guarantee certification.


7. Having TUV and ISO certification.


8. Honor of experiences worked for 2007 Special Olympic, 2008 Beijing Olympic Games, Asian Games,

Shanghai Expo and World Youth Skiing Championships etc.


9. Best quality aluminium truss and stage, strict working production process.


10. Life-time after sales service.

Material Guarantee 6082

The proportion of chemical composition for 6061 and 6082 is different.

One of the most significant newer alloys is 6082, similar to 6061 but with better properties.

6082 has become popular in Europe because it has higher strengths which is allowable tensile strengths

are 10 to 18% higher for 6082 than 6061 and better general corrosion resistance than 6061.

6082 was adopted to be using in aviation industry.

SQB400 Allowable Loading
6082-T6 50*3mm tube as main tube 30*2mm as brace tube
Span LOAD ALL Unitformly distributed load(UDL) Centre point load(CPL) DEFLECTION
m ( ft ) kg kg/m kg (mm)
4 13.1 932 232.8 465.6 3
5 16.4 932 186.4 465.6 4
6 19.7 931.2 155.2 465.6 7
7 23 929.6 132.8 464.8 9
8 26.2 928 116 464 18
9 29.5 928.8 103.2 464 22
10 32.8 928 92.8 464 40
11 36 925.5 84.8 464 54
12 39.2 921.6 76.8 460.8 73
13 42.6 852.8 65.6 426.4 89
14 45.9 795.2 56.8 397.6 107
15 49.2 744 49.6 372 123
16 52.5 691.2 43.2 345.6 140

Applications:

►Celebration services: opening ceremonies, anniversary celebrations, housewarming celebration;

opened the ribbon cutting, the launching ceremony, the unveiling ceremony, the groundbreaking

ceremony for the completion ceremony, capping ceremony, the foundation stone laying ceremony, ,

the signing ceremony, the listing ceremony,, public relations etiquette; promotion of new products,

awards ceremony;

►Business services: press conferences, new product launches, the various types conferences such as for investment,order, awards, the annual meeting, customer appreciation, sightseeing exchanges

►Performances service: Business promotional performances, thank and return banquet, theatrical show,

the models show,the ethnic features performances, Chinese and foreign star invitation; stage design, and

production of the lighthouse for performing arts, performances facility ,stage lighting truss.

Photos

Stage Truss Systems Aluminum Square Truss For Outdoor Parties Length 0.5 - 4m

Stage Truss Systems Aluminum Square Truss For Outdoor Parties Length 0.5 - 4m

Stage Truss Systems Aluminum Square Truss For Outdoor Parties Length 0.5 - 4m

Choosing Ledika Truss, you will get not only the products, but also the better service, and better operating mode.


Welcome contact us for long term cooperation !

Welcome contact us for long term cooperation !

Welcome contact us for long term cooperation !
