Anti Glare Diameter 23mm Led Lighting Lens 36 Degree For Linear Spot Lamp
Anti Glare Diameter 23mm Led Lighting Lens 36 Degree For Linear Spot Lamp
Anti Glare Diameter 23mm Led Lighting Lens 36 Degree For Linear Spot Lamp
Anti Glare Diameter 23mm Led Lighting Lens 36 Degree For Linear Spot Lamp
Specifications
Brand Name :
Wisertop
Model Number :
WT-15@10-36A-XP3 (PMMA)
Certification :
Rohs
Place of Origin :
China
MOQ :
1pc
Price :
Shenzhen Wisertop Technology Co.,Ltd
Supply Ability :
100,000 day
Delivery Time :
1-2 weeks
Packaging Details :
Master carton
Light source :
Osram 3535
Material :
PMMA
Working temperature :
-40°C~+70°C
Certificates :
Rohs
Lens type :
TIR Les
Efficiency :
92%
Description

Diameter 23mm Linear spot Lens PMMA material Viewing angle 36° for Linear spot lamp

Application: Linear light, Celling light, Recessed light

Lens material: PMMA material

Features:
● High directionality, accurate light control route
● It can be applied to the shading angle of larger lamps, which can ensure high light outlet efficiency under the condition of ultra-small outlet.
● Greater shade angles can bring better anti-glare lighting effects
● Light distribution type of clean, uniform and complete faded spots

Fit SMD light source: XPE/SST10/¢3mm COB

Specifications
Part no Light-emitting surface FWHM Size (mm) Typ.eff Material
WT-23@13-24A-XP3-S1 XPE/SST10/¢3mm COB 24° φ23.2×12.5 0.92 PMMA
WT-23@13-36A-XP3-S1 XPE/SST10/¢3mm COB 36° 0.92 PMMA

Anti Glare Diameter 23mm Led Lighting Lens 36 Degree For Linear Spot Lamp

Anti Glare Diameter 23mm Led Lighting Lens 36 Degree For Linear Spot Lamp

FAQ
1) Can l have a sample order?
A: Yes, we welcome sample order to test and check quality.
Mixed samples are acceptable.
2) When can l get the quotation?
A: We usually give you an offer within 12 hours after we getyour inquiry,. But if you want to get the offer ASAP,please call us or emal us that we can
3) What is the lead time?
A:Sample needs about 3-5 days prepared, mass production time needs 1-2 weeks normally.
4) What are your main products?
A: Our main products are indoor lenses.
