0.75mm Height 2835 UV led diode Top View Purple Chip LED 365nm 375nm 385nm 395nm 400nm
0.75mm Height 2835 UV led diode Top View Purple Chip LED 365nm 375nm 385nm 395nm 400nm
0.75mm Height 2835 UV led diode Top View Purple Chip LED 365nm 375nm 385nm 395nm 400nm
0.75mm Height 2835 UV led diode Top View Purple Chip LED 365nm 375nm 385nm 395nm 400nm
Specifications
Brand Name :
DOUBLE LIGHT
Model Number :
DL-TOP2835UVC-UV365
Certification :
ISO9001:2008/ROHS
Place of Origin :
China (mainland)
MOQ :
10,000pcs
Payment Terms :
Telegraphic Transfer in Advance (Advance TT, T/T)
Supply Ability :
15,000,000pcs per Day
Delivery Time :
15 working days after received your payment
Packaging Details :
Dimensions per Unit:0.28 × 0.2 × 0.13 Meters • Weight per Unit:3.5 Kilograms • Units per Export Carton:40000 • Export Carton Dimensions L/W/H: 0.45 × 0.28 × 0.27 Meters • Export Carton Weight:14.2 Kilograms
Product Name :
5mm Purple LED
Package :
5mm UV LED
Emitted Color :
Purple
Peak Emission Wavelength :
360-420nm
Chip Material :
InGaN
Lens Type :
Water Clear
Forward Voltage @20ma :
3.3v
Luminous Intensity :
28mcd
Viewing Angle :
120 Deg
Description

0.75mm Height 2835 Top View Purple Chip LED 365nm 375nm 385nm 395nm 400nm

  • Features:
  1. P-LCC-2 package.
  2. White package.
  3. Optical indicator.
  4. Colorless clear window.
  5. Ideal for backlight and light pipe application.
  6. Inter reflector.
  7. Wide viewing angle.
  8. Suitable for automatic placement equipment.
  9. Suitable for vapor-phase reflow, Infrared reflow and wave solder processes.
  10. Available on tape and reel (8mm Tape).
  11. The product itself will remain within RoHS compliant Version.

  • Descriptions:
  1. The 2835 series is available in soft red, orange, yellow, green, blue and white. Due to the package design, the LED has wide viewing angle and optimized light coupling by inter reflector. This feature makes the SMT TOP LED ideal for light pipe application. The low current requirement makes this device ideal for portable equipment or any other application where power is at a premium.

  • Applications:
  1. Automotive: Backlighting in dashboards and switches.
  2. Telecommunication: Indicator and backlight in telephone and fax
  3. Indicator and backlight for audio and video equipment.
  4. Indicator and backlight in office and family equipment.
  5. Flat backlight for LCD’s, switches and symbols.
  6. Light pipe application.
  7. General use.

Part No. Chip Material Lens Color Source Color
DL-TOP2835UVC-UV365 InGaN Water Clear Purple

Purple LED Absolute Maximum Ratings at Ta=25℃

Parameters Symbol Max. Unit
Power Dissipation PD 150 mW

Peak Forward Current

(1/10 Duty Cycle, 0.1ms Pulse Width)

 IFP 120 mA
Continuous Forward Current IF 30 mA
Reverse Voltage VR 5 V
Electrostatic Discharge (HBM) ESD 1000 V
Operating Temperature Range Topr -40℃ to +80℃
Storage Temperature Range Tstg -40℃ to +85℃
Soldering Temperature Tsld 260℃ for 5 Seconds
Notes:
1. It is strongly recommended that the temperature of lead be not higher than 55℃.
2. Proper current derating must be observed to maintain junction temperature below the maximum.
3. LEDs are not designed to be driven in reserve bias.

Purple LED Electrical Optical Characteristics at Ta=25℃

Parameters Symbol Min. Typ. Max. Unit Test Condition
Luminous Intensity * IV 15 28 --- IF=30mA
Radiant Intensity Ie 5.05 7.07 ---- mW/sr IF=30mA
Viewing Angle * 2θ1/2 --- 120 --- Deg IF=30mA
Peak Emission Wavelength λp --- 360 --- nm IF=30mA
Dominant Wavelength λd --- 365 --- nm IF=30mA
Spectral Line Half-Width △λ --- 25 --- nm IF=30mA
Forward Voltage VF ---- 2.63 ---- V IF=5mA
---- 2.84 ---- IF=20mA
3.0 3.30 --- IF=30mA
Reverse Current IR --- --- 10 µA VR=5V

Notes:

  1. Luminous Intensity Measurement allowance is ± 10%.
  2. θ1/2 is the off-axis angle at which the luminous intensity is half the axial luminous intensity.
  3. The dominant wavelength (λd) is derived from the CIE chromaticity diagram and represents the single wavelength which defines the color of the device.

Company introduction:

HongKong Double Light Electronics was founded in 2005 as a professional LED manufacturer located in Shenzhen, China. We mainly produce a wide range of products with automatic production lines, which include THT LEDs, chip LEDs, LED displays, infrared LEDs, dot matrix, LCD backlights and LED lighting fixtures.

0.75mm Height 2835 UV led diode Top View Purple Chip LED 365nm 375nm 385nm 395nm 400nm

why choose DOUBLE LIGHT?
1. Well-known chip material
2. 99.99% gold wire bonding
3. 3 years warranty
4. Over 10 years work experience technical service team
5. 24 hours service Professional sales team
6. Free Sample is available
7. Fast delivery
8.100% QC inspection Before Shippment

9. Aiming at the consult of "high quality, zero defect”, give you the best quality, best service.
