​1.90mm Height Top View High Bright Smd 3528 Led White Light Pipe

• Features:

• P-LCC-2 package.
• White package.
• Optical indicator.
• Colorless clear window.
• Ideal for backlight and light pipe application.
• Inter reflector.
• Wide viewing angle.
• Suitable for automatic placement equipment.
• Suitable for vapor-phase reflow, Infrared reflow and wave solder processes.
• Available on tape and reel (8mm Tape).
• The product itself will remain within RoHS compliant Version.

• Descriptions:

• The TOP3528 series is available in soft red, orange, yellow, green, blue and white. Due to the package design, the LED has wide viewing angle and optimized light coupling by inter reflector. This feature makes the SMT TOP LED ideal for light pipe application. The low current requirement makes this device ideal for portable equipment or any other application where power is at a premium.

• Applications:

• Automotive: Backlighting in dashboards and switches.
• Telecommunication: Indicator and backlight in telephone and fax
• Indicator and backlight for audio and video equipment.
• Indicator and backlight in office and family equipment.
• Flat backlight for LCD’s, switches and symbols.
• Light pipe application.
• General use.

• Package Dimension:
• Absolute Maximum Ratings at Ta=25℃

• Parameters	Symbol	Max.	Unit
  Power Dissipation	PD	95	mW
  Peak Forward Current (1/10 Duty Cycle, 0.1ms Pulse Width)	IFP	100	mA
  Continuous Forward Current	IF	25	mA
  Reverse Voltage	VR	5	V
  Electrostatic Discharge (HBM)	ESD	400	V
  Operating Temperature Range	Topr	-40℃ to +80℃
  Storage Temperature Range	Tstg	-40℃ to +85℃
  Soldering Temperature	Tsld	260℃ for 5 Seconds

  Electrical Optical Characteristics at Ta=25℃

  Parameters	Symbol	Min.	Typ.	Max.	Unit	Test Condition
  Luminous Intensity *	IV	2000	2500	---	mcd	IF=20mA (Note 1)
  Viewing Angle *	2θ1/2	---	120	---	Deg	IF=20mA (Note 2)
  Chromaticity Coordinates	x	---	0.30	---		IF=20mA (Note 3)
  	y	---	0.31	---
  Forward Voltage	VF	3.00	3.30	3.80	V	IF=20mA
  Reverse Current	IR	---	---	10	µA	VR=5V

  Notes:

• Luminous Intensity Measurement allowance is ± 10%.
• θ1/2 is the off-axis angle at which the luminous intensity is half the axial luminous intensity.
• It use many parameters that correspond to the CIE 1931 2°. X, Y, and Z are CIE 1931 2° values of Red, Green and Blue content of the measurement.
• Typical Electrical / Optical Characteristics Curves

• (25℃ Ambient Temperature Unless Otherwise Noted)

  CIE Chromaticity Diagram:

•
•

  Chromaticity Coordinates Specifications for Bin Rank

  (IF=20mA, Ta=25℃)

  Color	Group	Chromaticity Coordinate Group
  White	Full	X	0.270	0.270	0.350	0.350
  		Y	0.240	0.290	0.380	0.330
  	A	X	0.270	0.270	0.297	0.297
  		Y	0.240	0.257	0.287	0.270
  	B	X	0.297	0.297	0.323	0.323
  		Y	0.270	0.287	0.317	0.300
  	C	X	0.323	0.323	0.350	0.350
  		Y	0.300	0.317	0.347	0.330
  	D	X	0.270	0.270	0.297	0.297
  		Y	0.257	0.273	0.303	0.287
  	E	X	0.297	0.297	0.323	0.323
  		Y	0.287	0.303	0.333	0.317
  	F	X	0.323	0.323	0.350	0.350
  		Y	0.317	0.333	0.363	0.347
  	G	X	0.270	0.270	0.297	0.297
  		Y	0.273	0.290	0.320	0.303
  	H	X	0.297	0.297	0.323	0.323
  		Y	0.303	0.320	0.350	0.333
  	I	X	0.323	0.323	0.350	0.350
  		Y	0.333	0.350	0.380	0.363

  Notes:

• Color coordinates measurement allowance is ± 0.01.
• One delivery will include up to two consecutive color ranks and three luminous intensity ranks of the products the quantity-ratio of the ranks is decided by Double liGHT
• Reel Dimensions:

•

  Carrier Tape Dimensions:

  Loaded quantity 2000PCS per reel.
