Datasheet:DL-TOP3528RGBC-A1.pdf Light source: RGB

1.90mm Height Top View Full Color Chip LEDs

Features:

• P-LCC-2 package.
• White package.
• Optical indicator.
• Colorless clear window.
• Ideal for backlight and light pipe application.
• Inter reflector.
• Wide viewing angle.
• Suitable for automatic placement equipment.
• Suitable for vapor-phase reflow, Infrared reflow and wave solder processes.
• Available on tape and reel (8mm Tape).
• The product itself will remain within RoHS compliant Version.

Descriptions:

• The BL-TOP3528 series is available in soft red, orange, yellow, green, blue and white. Due to the package design, the LED has wide viewing angle and optimized light coupling by inter reflector. This feature makes the SMT TOP LED ideal for light pipe application. The low current requirement makes this device ideal for portable equipment or any other application where power is at a premium.

Applications:

• Automotive: Backlighting in dashboards and switches.
• Telecommunication: Indicator and backlight in telephone and fax
• Indicator and backlight for audio and video equipment.
• Indicator and backlight in office and family equipment.
• Flat backlight for LCD’s, switches and symbols.
• Light pipe application.
• General use.

​

​

• Package Dimension:
•

• Notes:

• Luminous Intensity Measurement allowance is ± 10%.
• θ_1/2 is the off-axis angle at which the luminous intensity is half the axial luminous intensity.

• The dominant wavelength (λd) is derived from the CIE chromaticity diagram and represents the single wavelength which defines the color of the device.

• Typical Electrical / Optical Characteristics Curves

• (25℃ Ambient Temperature Unless Otherwise Noted)

  CIE Chromaticity Diagram:

• Reel Dimensions:

•

  Carrier Tape Dimensions:

  Loaded quantity 2000PCS per reel.

  For more details, please contact us.
