Specifications
Brand Name :
DOUBLE LIGHT
Model Number :
DL-257PGT-1PG70
Certification :
ISO9001:2008/ROHS
Place of Origin :
China (mainland)
MOQ :
10,000pcs
Price :
US$ 0.01 per unit (Pieces)
Payment Terms :
Telegraphic Transfer in Advance (Advance TT, T/T)
Supply Ability :
15,000,000pcs per Day
Delivery Time :
5-10 working days after received your payment
Packaging Details :
Dimensions per Unit:0.28 × 0.2 × 0.13 Meters • Weight per Unit:3.5 Kilograms • Units per Export Carton:40000 • Export Carton Dimensions L/W/H: 0.45 × 0.28 × 0.27 Meters • Export Carton Weight:14.2 Kilograms
Product Name :
Rectangle 2x5x7mm dip led
Emitted Color :
Green
Peak Emission Wavelength :
518nm
Lens Color :
Green Transparent
Forward Voltage @20ma :
3.0-3.2v
Forward Current :
30mA
Luminous Intensity :
600-700mcd
Viewing Angle :
70-120Deg
Description

2x5x7mm Rectangular led lamp Green led indicator lights Square Rectangle Clear Transparent through Hole LED

Features:

  1. Choice of various colors.
  2. 2*5*7mm Rectangular.
  3. Available on tape and reel.
  4. Reliable and robust.
  5. The product itself will remain within RoHS compliant Version.

Descriptions:

  1. The series is specially designed for applications requiring higher brightness.
  2. The LED lamps are available with different colors, intensities.

Applications:

  1. TV set.
  2. Monitor.
  3. Telephone.
  4. Computer.
  5. Circuit board.
  6. Status indicators.
  7. Commercial use.
  8. Advertising Signs.
  9. Back lighting.


Package Dimension:

Rectangular Led Lamp Green Led Indicator Lights Square Clear Transparent Through Hole LED

​

Notes:

  1. All dimensions are in millimeters (inches).
  2. Tolerance is ± 0.25mm (.010″) unless otherwise noted.
  3. Protruded resin under flange is 1.00mm (.039″) max.
  4. Specifications are subject to change without notice.
  • Absolute Maximum Ratings at Ta=25℃
Parameters Symbol Max. Unit
Power Dissipation PD 120 mW

Peak Forward Current

(1/10 Duty Cycle, 0.1ms Pulse Width)

 IFP 100 mA
Forward Current IF 30 mA
Reverse Voltage VR 5 V
Operating Temperature Range Topr -40℃ to +85℃
Storage Temperature Range Tstg -40℃ to +100℃

Lead Soldering Temperature

[4mm (.157″) From Body]

 Tsld 260℃ for 5 Seconds

Electrical Optical Characteristics at Ta=25℃

Parameters Symbol Min. Typ. Max. Unit Test Condition
Luminous Intensity * IV 600 700 --- mcd IF=20mA (Note 1)
Viewing Angle * 2θ1/2 --- 70 --- Deg IF=20mA (Note 2)
Peak Emission Wavelength λp --- 518 --- nm IF=20mA
Dominant Wavelength λd --- 523 --- nm IF=20mA (Note 3)
Spectrum Radiation Bandwidth Δλ --- 35 --- nm IF=20mA
Forward Voltage VF 2.8 3.3 --- V IF=20mA
Reverse Current IR --- --- 10 µA VR=5V

Notes:

  1. Luminous Intensity Measurement allowance is ± 10%.
  2. θ1/2 is the off-axis angle at which the luminous intensity is half the axial luminous intensity.
  3. The dominant wavelength (λd) is derived from the CIE chromaticity diagram and represents the single wavelength which defines the color of the device.

Rectangular Led Lamp Green Led Indicator Lights Square Clear Transparent Through Hole LED

Why choose DOUBLE LIGHT?
1. Well-known chip material
2. 99.99% gold wire bonding
3. 3 years warranty
4. Over 10 years work experience technical service team
5. 24 hours service Professional sales team
6. Free Sample is available
7. Fast delivery
8.100% QC inspection Before Shippment
9. Aiming at the consult of "high quality, zero defect”, give you the best quality, best service.
