150w Linear Warehouse Light / Llinear LED Lighting with 5 years warranty
150w Linear Warehouse Light / Llinear LED Lighting with 5 years warranty
150w Linear Warehouse Light / Llinear LED Lighting with 5 years warranty
150w Linear Warehouse Light / Llinear LED Lighting with 5 years warranty
Specifications
Brand Name :
GRANDOL/OEM
Model Number :
GKT-120-150W
Certification :
IEC , CE , ROHS, EMC, LVD, ISO9001:2008
Place of Origin :
Shenzhen, China
MOQ :
100 pcs
Price :
usd15-25/PCS
Payment Terms :
T/T, L/C
Supply Ability :
20,000 pcs/month
Delivery Time :
10-15days
Packaging Details :
1pcs/640**205*165mm/4.2kgs/ctn
Lamp Power :
150w
Light Source :
SAMSUNG SMD5630
Lumens Flux :
130lm/w
Driver :
Meanwell
Input :
90-277vac
Certificates :
IEC/CE/ROHS/TUV/SAA
Description

150w Linear Warehouse Light / Llinear LED Lighting with 5 years warranty

FEATURES :

1. Samsung LED, 105lm/w;
2. 4FT 120W LED to replace 6x36W T8 Fluorescent High Bay Fixture
3. Suitable for height of 6m to 12m
5. HLG Meanwell Brand driver, 50000 hrs long lifespan
6. IP65 tri-proof, for indoor and outdoor
7. Warranty: 5 Years

8.Dimmable: 1-10V, DALI, Microwave Motion Sensor, Daylight Sensor

PARAMETERS:

Model GKT-80-60W GKT-90-100W GKT-120-150W GKT-150-200W
Power(±10%) 80W 100W 150W 200W
Input Voltage(Hz) 90-277VAC(50/60Hz)
Power Factor(PF) >0.9
LED QTY (SMD5730)/PCS 252 336 420 588
Lumen(±10%)Lm 6000 10000 15000 20000
Effective(±10%)Lm/W 100 100 100 100
CCT(K) F3000,F4000,F6500
CIR(Ra) >80
Beam angle 120°
Working temperature -20℃～45℃
Working Humility 10%~90%RH
Storage Temperature -30℃～60℃
Life Span of light source ≧30000 H
Materials

AL+PC

Frost Cover
IP Grade IP65
Certification Comply with CE ROHS requirements

150w Linear Warehouse Light / Llinear LED Lighting with 5 years warranty

150w Linear Warehouse Light / Llinear LED Lighting with 5 years warranty

Applications:

1. Free workshop ( freight house / warehouse )
2. Sports center ( gym / natatorium / badminton court )
3. Service area ( supermark / school / subway / buss station / airpot )
4. Manufacturing ( plant / assembly area /production area

ATTENTIONS:


1. The light’s waterproof grade is IP65, able to withstand rains, but it can’t work under water.
2. The light’s operating at working temperature between -20℃ and 45℃.

3. Make sure the products are out of reach from children,
4. Please don’t install in flammable ,explosive or corrosive circumstances,
5. Cut off power supply before and in installation process. If the product is damaged due to mal-operation, it will invalid the warranty.
