Outdoor Recreation Multi purpose LED hard hat headlamp , Miner Cap Lamp Hunting

1. Feature for Cordless Mining Lights

Wateproof grade : IP68
High Beam Brightness : >4000LUX

Anti-explosive grade : Ex ia
High Quality Material : Germany Bayer PC
Portable Light Weight : 171g , similar to the weight as a cell phone, more portable.
Multi-function lighting modes : main light - auxiliary light

2. General Guide PICTURES

3. Our products can be widely used for :

• camping, travelling, cycling
• tool, maintenance lighting
• fishery, diving, fire-fighting
• military, architecture, living
• furniture, farm lighting
• night fishing, car-carrying, road and railway lighting, forest farm

4. Product Advantages:

Safety : Over-charging protection , over-discharging protection, protection in electrical short-circuit,

automatic power-off on the socket , 100,000 hours LED’s Lifetime

Portability : All-in-one structure, Small in size , light in weight (only 171g for whole product),

inductive charging, easy usage

Efficiency : more than 15hours at full brightness, over 80hours at back up led brightness.Over4000lux

Brightness

Environmental : Li-ion battery is free for maintenance, and the material of li-ion is environmental, use

1Watt high power LED as the main light, and 6pcs backup LED’s to save power

Economy : three times longer than lead and acid cap lamp and saving in maintenance makes the product

more compatible in price

Charger input power : AC100-240V / 50-60Hz. Charging time: 6hours, continuous discharging time: more than 15hours at full brightness, over 80hours at back up led brightness.

Type of protection : IMI EXia IICT6 (Zone 1 and 2)

Protection category : IP68

5.Troubles and troubleshootings

Correct Use:

The GREEN LIGHTING​ cordless cap lamp is a camera miner’s safety lamp.
The device is attached to a safety helmet, designed to accommodate front mounted attachments, and its power source, battery and housing, is integreted into the cap lamp housing.

The device is primarily designed for underground mining activities and emergency services.

Transportation: The transport process is not allowed by the severe mechanical shock and exposure Rain, prevent throw throwing , rolling, pressure .

Storage: miner's lamp should be stored at ambient temperature 0~40℃,relative bumidity of 45%-90%. Dry, clean ,and wellventilated, non-corrosive medium warehouse, should stay away frion fire and heat, If long-term storage, please filled to 80% of capacity, and charge about 5hours after three to four months.

CAUTION:

This product supports life and health in an underground environment.
Inappropriate use, maintenance or tampering may affect the function of the device and
therefore compromise the product’s ability to support life and protect against harm

ATTENTION:

When using the GREEN LIGHTING​ Cordless Cap Lamp the following safety instructions must be observed:
• Device shall be operated by qualified personnel.
• Before each use, check the functionality of the device.
• Be aware of the procedures for handling electrostatically sensitive electronics, which include GREEN LIGHTING ​cap lamps.
• This device contains electrostatically sensitive components. Do not open or repair the device without using appropriate electrostatic protection.
• Be aware of the warranty regulations.
• Do not charge in hazardous areas.
• Charge only with approved charging devices.

8.About us

GREEN LIGHTING TECHNOLOGY CO.,LTDis an expertised manufacturer of explosion-proof mining lamps which is located in ShenZhen area in china.Our factory has skilled experience in underground working lamps development and production. We focus on the development and innovation, and we pay more attention to great quality. We also have established our own marketing department for foreign sales.
