Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm
Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm
Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm
Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm
Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm
Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm
Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm
Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm
Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm
Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm
Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm
Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm
Specifications
Place of Origin :
Shaanxi, China
Brand Name :
Razorlux
Model Number :
RGL2-400A
Certification :
ce, LVD, RoHS, Saa, UL
Packaging Details :
1.EPS Foam+carton(ONE UNIT PER CARTON)
2.Carton Size(mm):550*450*415mm
3.One 20'' Container can accept 250 Units
Price :
$767.00/Pieces
Color Temperature(CCT) :
2700-6500K, Cool White
Lamp Luminous Efficiency(lm/w) :
130, 130
Lighting solutions service :
Lighting and circuitry design, DIALux evo layout
Working Time (hours) :
50000
Input Voltage(V) :
80~315Vac, (347Vac available on request)
Beam Angle(°) :
40° 60° 120° 140°
Lamp Body Material :
Aluminum Alloy
Application :
Sports Stadiums
Lamp Luminous Flux(lm) :
52000lm, 52000lm
Working Temperature(℃) :
-40C ~ 60C / -40F ~ 140F, -40 - 60
Warranty(Year) :
5-Year
Product Name :
Stadium Lighting LED
IP Class :
IP 65 (Upgradeable to IP 67)
Luminous Efficacy(lm/w) :
130
Description
Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm
5 Years Warranty Round Waterproof IP67 Anti-exposure Outdoor 400W Stadium Lighting LED

Hockey rink lighting needs to illuminate all the fast-paced action that a hockey game delivers. After all, the puck is only 4” and can travel 100 mph. Whether attending a game in an arena or watching from home, the best viewing experience is one where the hockey rink is extremely well-lit.

LED lights provide energy efficient lighting that will decrease your energy consumption and costs, while increasing the light quality and providing even surface illumination for a whiter, brighter hockey arena.

Model
RGL2-400A
Beam Angle
40° 60° 120° 140°
Stable Flux (5700K after 1 hour)
52000lm
Dimension (mm)
468*388*367

Power Consumption
LEDs
360W
Driver
40W
Total
400W
Replace HID Lamp
800~1000W
Net Weight
15kg (33lbs)
Color Temperature
2700-6500K
Color Rendering
≥Ra75 (≥Ra80, ≥Ra90 available on request)
Working Life
≥50000Hrs
Housing Material
Aluminum & Powder coating
Power Supply
Meanwell
IP Class
IP 65 (Upgradeable to IP 67)
IK Class
IK 10
Insulation Class
Class I
Working Temperature
-40C ~ 60C / -40F ~ 140F
Working Humidity
10% ~ 95%
AC Input
110-480Vac input voltage without additional adapter
DC Input
100 ~ 400Vdc, 500Vdc ~ 800Vdc
THD
<10%
Power Factor
≥0.98
Warranty
LED Module
5 years
Driver
5 years
Housing
10 years

Features:

✦ 80% lumen maintenance over 50,000hours.
✦ 110-480Vac input voltage without additional adapter.
✦ 0-10VDC, DALI and wireless control available.
✦ Photocell & motion sensor system available.
✦ Built-in surge protection & thermal protection.
✦ Mercury free, No UV or IR.
✦ High uniformity & color rendering index.
Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lmRound 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lmRound 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm

Features & Specifications of 1-10V Dimmable led flood light 400Watt

  • Patented Multi-function design, suitable for all working environments.
  • Rated Power: 400W-1200W
  • Input Voltage: AC90-305, DC127-431
  • Color Temperature: 2700K-6500K
  • Lamp Efficiency: 130LM/W
  • Beam Angle: 15°, 20°, 30°, 40°, 60°, 120°, 140°x60°.
  • CRI: Ra>75
  • IP Grade: IP65/IP67
  • Bracket: Stainless Steel
  • Net Weight: 15KG
  • Warranty: 5 Years

FAQ:

1. Are you a factory or trading company:

We are a factory located in Xi'an China, established in 2006.

2. What is your product range?

Our wide product range includes floodlight, street light, pendant light, and power from 60W to 1200W.

3. How many days of production will the order take?

Normally 7-15 days, depending on the order quanity.

4. How do you ship goods abroad?

For sample, trial order, or small quantities we will suggest shipping by air, for large quantity and bulk order we recommend shipping by sea.

5. Does your product support smart control like sensor, dimming, DALI, etc.

They support all of these features, please tell our sales during your negotiation when you need such features.

6. How do you deal with failed lights?

During the warranty period, we will send customer free part or lamp after checking the evidence. After warranty, we only charge the component fees, no extra charge for our customer.
