Full Color LED Video Wall Screen / P3 Indoor LED Display 3840Hz 576x576mm
Full Color LED Video Wall Screen / P3 Indoor LED Display 3840Hz 576x576mm
Full Color LED Video Wall Screen / P3 Indoor LED Display 3840Hz 576x576mm
Full Color LED Video Wall Screen / P3 Indoor LED Display 3840Hz 576x576mm
Full Color LED Video Wall Screen / P3 Indoor LED Display 3840Hz 576x576mm
Full Color LED Video Wall Screen / P3 Indoor LED Display 3840Hz 576x576mm
Specifications
Brand Name :
Weiye
Model Number :
Weiye Color 4
Certification :
CCC FC CE FC CB ROHS
Place of Origin :
China
MOQ :
1 pcs / 1 sqm
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
5,000 square meters per month
Delivery Time :
7-12 working days after received your payment
Packaging Details :
Carton，Honeycomb box，Wooden box，Flight Case
product name :
Full color P3 indoor led display led video wall led screen LED Display Screen
Pixel pitch （mm） :
P3
Refresh rate （Hz） :
≥1920 / 3840
Cabinet size: :
576x576mm
Module size （mm） :
192 x 192
Module resolution （WxH） :
3 x 3
Life-span: :
more than 100000 hours
Description

Full color P3 indoor led display led video wall led screen LED Display Screen

Function and Technology Character Introduction:

1, Bright colors, long life

2, High brightness, good color consistency

3, The product uses high-quality lamps, which can achieve a wide color gamut of ≥110%

4, High refresh chip, refresh up to 3840Hz

Products Applications:

Widely used in churches, control command centers, video surveillance centers, high-definition information release, conference display systems and other commercial venues

SPECIFICATIONS Parameters:

Product parameter
led module
Pixel pitch (mm) P3
Pixel density (point /㎡) 111111
Module size (mm) 192X192
Module resolution (WxH) 64X64
Package form SMD2121
scanning method 1/32S
Refresh rate (Hz) ≥1920/3840(Optional )
White balance brightness (Nits) ＞700
Color temperature (K) 3200-9300(Adjustable )
Gray scale ≥14bit
Frame change frequency 60-120Hz
Viewing angle (horizontal/vertical) 160°/160°
Protection level (front/back) IP31
Average/peak power consumption (W/㎡) 850/350
Face mask Have
Cabinet
Cabinet size (mm) 576X576
Screen weight (Kg) 8.5
Cabinet module composition (WxH) 3X3
Cabinet resolution (WxH) 192X192
Flatness (mm) ≤0.2
Maintenance method Full front maintenance
Cabinet material Die-cast aluminum
Application Environment
Input voltage (V) 110-240
Operating temperature (℃) -20~50
Working humidity (RH) 10%-95%
Service life (H) ≥100000
Model type (using video processor) AV,S-Video,VGA,DVI,HDMI,SDI,DP
Control distance Category 5 network cable :＜100m,Single mode fiber :＜10km

weiye color series led strip display screen advantage:

1, High-quality tube, stable quality

2, Wide color gamut, richer color layers

3, Rich color levels, better color reproduction

4, Back wireless design Wireless connection between boxes, exposed wires on the screen, and internal cables using aviation plugs, which are stable and firm to ensure trouble-free power transmission. A quick lock link is used between the box body and the box body, which is convenient, fast and firm to install, and is neat and tidy at the same time.

5, Constant output current, no flicker when taking pictures with high refresh effect
