12v 10a 120Watt AC DC Power Adapter Level VI Energy for led strips CCTV camera with CE UL marked

1. Product Features:

- Rated power: 120W
-The efficiency is as high as 90%
- Input voltage: 100-240VAC
-The power factor: built-in PFC function, 00Vac-240VAC , PF>0.9 when full load
-The output current: 12Vdc 10A 120Watt
- Protection: short circuit / overload / over temperature
-Meet the requirements of EMC (EN55015 Class B)
- Meet CE safety requirements
-100% full load burn-in test
-High reliability

2. Product Overview :

The information described in detail the 200, 16.6A a long type series of non dimming
built-in active PFC function of single channel output LED driver power supply,
protection grade is IP20 indoor installation; with short circuit, over voltage, temperature
protection function.

3, Basic Electrical Characteristics :

Input voltage :

output characteristics :

4, output short circuit protection :

Output short circuit, the power supply into the protection of the state, after the failure to
lift the power to automatically resume normal work .

5, output overload protection :

When the output load current is more than 1.5 times, the product enters the the state of
the protection, the product is not damaged, when the fault is excluded, the power
automatically resume normal work

6, output over temperature protection :

When power supply working environment temperature exceeds 85 + 5 DEG C, OTP
power protection no output, below the point of internal power supply temperature is reset
to the protection and automatic restoration of power work

7, reliability requirements :

When the rated input voltage, full load, ambient temperature is 25 degrees Celsius, the
average power supply no failure time at least 50000 hours

8, safety rules :

(1) dielectric withstand voltage (high pressure) : I/P-O/P:3.75KVAC

(2) leakage current : 0.25mAmax at 240Vac/50Hz

(3) insulation resistance : I/P-O/P:≥50M O hm s/500V D C /25℃/70% R H

(4) safety standards : EN61347-1 Meet EN61347-1

(5) cooling mode : Natural cooling
